Help Center5tons Loading Foton/forland Dump Truck/tipper Body/Forland 4x2 Dump Truck Foton Tipper
Related Products
-
Brand New Cargo Body Parts for WholesalesUS$ 4,000 - 10,000MOQ: 1 Set -
Semi-trailer Refrigerator Semi TrailerUS$ 4,000 - 10,000MOQ: 1 Set
-
Foton New Design Light Dump Truck With Great PriceUS$ 10,000 - 13,000MOQ: 1 Unit
-
Dry Van Container Small Cargo VehiclesUS$ 4,000 - 10,000MOQ: 1 Set
-
Ckd Isolated Truck Body Panels Aluminum Truck PanelUS$ 4,000 - 10,000MOQ: 1 Set
Quick Details
| Drive Wheel: | Capacity (Load): | Horsepower: | |||
| Condition: | Transmission Type: | Emission Standard: | |||
| Fuel Type: | Engine Capacity: | Gross Vehicle Weight: | |||
| Place of Origin: | Brand Name: | Model Number: | |||
| Dimensions (L x W x H) (mm): | Internal cargo body dimensions: | Wheel base: |
Forland 4x2 Dump Truck Foton Tipper
--YUCHAI engine
--Tough Quality
--Competitive price
--Problem-free service
BJ3073DCPFA-S4
Engine | ||
Engine model and emission |
YC4D130-20 (Euro II) |
|
Engine type |
Vertical/in-line/water-cooling/ four-stroke/ supercharged intercooler |
|
Rated power of engine (kw/rpm) |
96/2800 |
|
Maximum torque (N.m/rpm) |
350/1600-1900 |
|
Engine displacement (L) |
4.214 |
|
Gearbox | ||
Gearbox type |
17D55F |
|
Rear axle | ||
Rear axle type |
Dead axle full float axle |
|
Rear axle load (T) |
10T |
|
Rear axle speed ratio |
6.833 |
|
Dumping type/oil cylinder size |
Single-top amplification mechanism/ HG-E160×740 |
|
Cabin type/width |
Single row of right-hand drive flat head/2,100 |
|
Drive form |
4×2 |
|
Tire type/number |
9.00R20/7 |
|
Service brake type |
Drum type, air braking |
|
Parking brake type |
Energy storage spring rear wheel braking |
|
Steering device |
Power steering |
|
Weight parameter | ||
Curb weight (Kg) |
6490 |
|
Rated load capacity (Kg) |
7000 |
|
Performance parameter | ||
Dimension parameters | ||
Overall dimensions (LxWxH)mm |
6720x2350x2720 |
|
Internal cargo body dimensions (LxWxH)mm |
4300x2170x800 |
|
Cargo body capacity (m³) |
7.46 |
|
Wheelbase (mm) |
3700 |
|
Front/rear wheel track (mm) |
1778/1721 |
|
Capacity of the fuel tank (L) |
140 |
|
Standard configuration |
Heater,Spare tire, electronically controlled flameout, adjustable steering wheel,air-conditioner |
|
In the past 15 years, we only do a truck, we are more professional.
Note: The cab, engine, gearbox, tire,color,cargo body size and others have options.
1 Due to improvements made to the product, data herein is subject to change without notice.
2. Different outfits are provided for the different configurations of the motor vehicles.
3. Affected by the reproduction conditions, the pictures and data differ somewhat from the actual motor vehicles.
4. JOYFLY reserves the rights to make final explanations
nude packing
We are looking for long term cooperation with customers. Therefore, if there is any quality feedback, we shall provide technical support and after sales service promptly. Easy to wear off parts list for each model is available upon customer's request. Service parts shall be sent along with each complete truck as well to ensure easy maintenance and service of each truck.
