Trailer Landing Gear

FOB Price

USD $120 - $136 / Pair

5 Pairs(Min.Order)

Supply Ability 25000 Pair / Pairs per Month
Port Xiamen Qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Parts:	Trailer Plugs	OEM No.:	TMLO-28	Max Payload:	80T
Size:	14''-19''	Place of Origin:	Fujian, China	Brand Name:	TINMY
Model Number:	TMLO-28

Product Description

JOST Type White Landing Gear:

Gearbox Inside details:

Item No.	Travel	Static Capacity	Lifting Capacity	Lift Speed/turn		Weight (Kg)	Remarks
Item No.	Travel	Static Capacity	Lifting Capacity	max	min	Weight (Kg)	Remarks
TMLI-25	14"/17"/19"	80T	25T	6	0.67	100	single-side operation
TMLI-28	14"/17"/19"	80T	28T	7.5	0.83	102	single-side operation
TMLI-30	14"/17"/19"	80T	30T	7.5	0.7	108	single-side operation

Gearbox Outside details:

Item No.	Travel	Static Capacity	Lifting Capacity	Lift Speed/turn		Weight (Kg)	Remarks
Item No.	Travel	Static Capacity	Lifting Capacity	max	min	Weight (Kg)	Remarks
TMLO-25	14"/17"/19"	80T	25T	4.33	0.57	108	single-side operation
TMLO-28	14"/17"/19"	80T	28T	5.42	0.72	110	single-side operation
TMLO-30	14"/17"/19"	80T	30T	5.42	0.72	116	single-side operation
TMLO-35	14"/17"/19"	80T	35T	5.42	0.72	120	single-side operation

Note:

1. Gear box inside and outside with JOST,FUWA , Holland type for semi trailer.

2. The main capacity including 9ton,11ton,25ton,28ton,30ton,35ton.
3 tons and 6 tons landing gears are also available.

3. Competitive price and high quality.

4. Certificate: ISO/TS16949

Function & Attention:
1. Landing Gear is one of the important equipments of semi-trailer. It is adopted to lift and load semi-trailer after leaving and to use as lifter while vehicle maintenance.
2. Landing Gear has slow and fast two speed. Please use slow speed when loading. It is easy to operate. Do not use fast speed. It is possible to injure landing gear.
