Help CenterSemi Trailer Landing Gear
US$ 115 - 130
MOQ: 5 Pairs
Key Specifications
Get Latest Price
Parts:
Trailer Suspension
OEM No.:
TMLO-25
Max Payload:
80T
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Parts
Trailer Suspension
OEM No.
TMLO-25
Max Payload
80T
Size
25Ton - 35 Ton
Place of Origin
Fujian, China
Brand Name
TINMY
Model Number
TMLO-25
Specifications
Landing Gear1,Gear box Inside & Outside
2,Capacity:9ton,11ton,25ton,28ton,30ton,35ton
3, ISO 9001:2000 /TS16949
Semi Trailer Landing Gear
1,THE LIFTING CAPACITY USUALLY COMES FROM 9T TO 35T.
2,OUTSIDE AND INSIDE GEAR BOX.
3, CERTIFICATE OF ISO 9001:2000 /TS16949.
4, FOR VARIOUS TRAILER BRAND, LIKE FUWA, JOST, HOLLAND,ETC.
Gearbox Inside details
| Item No. | Travel | Static Capacity | Lifting Capacity | Lift Speed/turn | Weight (Kg) | Remarks | |
| max | min | ||||||
| TMLI-25 | 14"/17"/19" | 80T | 25T | 6 | 0.67 | 100 | single-side operation |
| TMLI-28 | 14"/17"/19" | 80T | 28T | 7.5 | 0.83 | 102 | single-side operation |
| TMLI-30 | 14"/17"/19" | 80T | 30T | 7.5 | 0.7 | 108 | single-side operation |
Gearbox Outside details
| Item No. | Travel | Static Capacity | Lifting Capacity | Lift Speed/turn | Weight (Kg) | Remarks | |
| max | min | ||||||
| TMLO-25 | 14"/17"/19" | 80T | 25T | 4.33 | 0.57 | 108 | single-side operation |
| TMLO-28 | 14"/17"/19" | 80T | 28T | 5.42 | 0.72 | 110 | single-side operation |
| TMLO-30 | 14"/17"/19" | 80T | 30T | 5.42 | 0.72 | 116 | single-side operation |
| TMLO-35 | 14"/17"/19" | 80T | 35T | 5.42 | 0.72 | 120 | single-side operation |
