Box Truck

Trademark: VOLLAND/MUDAN

Model: ZTP1083X

Overall size: 6960(L)x2180(W)x2840(H)mm

Cargo body size: 5000(L)x1950(W)x1550(H)mm

Wheelbase: 3800 mm

Curb vehicle weight: 3310 kg

Gross vehicle weight: 8405 kg

Seating capacity: 3 persons

Payload: 5000 kg

Fuel tank:80L

Suspension: Leaf springs

Brake: Hydraulic system

Min ground clearance: 185(mm)

Engine:

1.model:CY4102BZLQ

   type:diesel,4-cylinder,in line,water-cooler,direct injection,turbocharged,intercooler/

   bore&stroke:102X118/displacement(cc):3856 /compression ratio:17:1/

   max power: 88Kw/2800rpm /max torque:343N.M/2200rpm /

   Emission;Euro 2 /Fuel comsumption(L/100Km):11.5≤

2.model:CA4DX23-130

   type:diesel,4-cylinder,in line,water-cooler,direct injection,turbocharged,intercooler/

   bore&stroke:102X118 / displacement(cc):43857 / compression ratio:17.5:1/

   max power: 95.5Kw/2800rpm /max torque:380N.M/1800~2000rpm /

   Emission;Euro 2 /Fuel comsumption(L/100Km):11.5≤

3.model:YC4D130-20

   type:diesel,4-cylinder,in line,water-cooler,direct injection,turbocharged,intercooler/

   bore&stroke:108X115 / displacement(cc):4214

   max power: 96Kw/2800rpm /max torque:380N.M/1600~1900rpm /

   Emission;Euro 2 /Fuel comsumption(L/100Km):11.5≤

4.model:YCD4D22-122

   type:diesel,4-cylinder,in line,water-cooler,direct injection,turbocharged/

   bore&stroke:105X120 / displacement(cc):4156

   max power: 90Kw/2800rpm /max torque:355N.M/1800rpm /

   Emission;Euro 2 /Fuel comsumption(L/100Km):11.5≤

5.model:YCD4D32-129

   type:diesel,4-cylinder,in line,water-cooler,direct injection,turbocharged,intercooler/

   bore&stroke:105X120/ displacement(cc):4156

   max power: 95Kw/2600rpm /max torque:405N.M/1700rpm /

   Emission;Euro 2 /Fuel comsumption(L/100Km):11.5≤

Gearbox:

5 speed manual

Axle:

Front:"I"type beam axle

Rear:double curve cone of gear,single-stage deceleration,pipe type

Brake system:

Service brake:Air brake

Parking brake:Style of central drum

Standard: AM/FM stereo cassette player, front heater, steel wheel discs, 8.25-16 tire

Options: Power steering, radial tires

Shipment: By containers

Standard: ISO9001

Productivity:  10,000units /year

Unit Price/Payment:  Negotiable

Origin:  China

Packing:  In Container

Min. Order:  1

Transportation:  By Sea.box truck
