Help CenterPhillaya Truck Trailer Supplier Official Manufacturer 37m Concrete Pump Truck
Related Products
-
Phillaya Truck Trailer Supplier Official Manufacturer 37m Concrete Pump TruckUS$ 100,000 - 200,000MOQ: 1 Set -
Sino Truck / Howo Mobile Concrete Mixer / Tank Semi Trailer (With Truck Head Available)US$ 15,000 - 25,000MOQ: 1 Set
-
Sino Truck / Howo Concrete Cement Mixer Truck / Tank Semi Trailer (With Truck Head Available)US$ 15,000 - 25,000MOQ: 1 Set
-
Howo Sino Truck Brand Concrete Mixer Truck for Sale 6-16CBMUS$ 40,000 - 60,000MOQ: 1 Set
-
Howo 6x4 Self Loading Concrete Mixer Truck for SaleUS$ 10,000 - 13,500MOQ: 1 Set
| ||||||
Tare Weight |
10800kg |
Overall Length |
9995mm |
|||
Overall Width |
2495mm |
Overall Width |
3780mm |
|||
Tank | ||||||
Capacity |
8CBM |
|||||
Mixing Tanker Sloping Angle |
14, 12,10 degree |
|||||
Mixing Tanker Revolving Speed |
12-20 (r/min) |
|||||
Key Accessories | ||||||
Engine |
Diesel engine or electrical motor |
|||||
Hydraulic Pump |
American Eaton or Italian TOP hydraulic pump |
|||||
Hydraulic Motor |
American Eaton or Italian TOP hydraulic motor |
|||||
Gear Box |
American Eaton or Italian TOP gear box |
|||||
Chassis |
Skeletal Chassis with special designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm; Bottom Flange 16mm,width 140mm. |
|||||
Axles |
2 axles, Fuwa |
|||||
Suspension |
Mechanical suspension/ |
|||||
Leaf Spring |
8-piece leaf spring |
|||||
King Pin |
2 Bolt-in King Pin |
|||||
Landing Gear |
Two-speed, manual operating, heavy duty landing gear |
|||||
Tyre |
11.00-20, 12.00-20, 11.00R20, 12.00R20, 11R22.5, 12R22.5-Optional |
|||||
Spare Tire |
One set of spare tire including a carrier |
|||||
Braking System |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks |
|||||
1. SEND US INQUIRY
2. WE SHALL REPLY YOU WITHIN 12 HOURS
3. NEGOTIATION ON YOUR NEEDED CONFIGURATION
4. CONFIRMATION ON TECH DATA→SIGN CONTRACT→30% DOWN PAYMENT/LC ISSUING→PRODUCTION
5. MANUFACTURING PROCESS UPDATED NEWS→ PRODUCTION COMPELEMENT
6. BALANCE PAYMENT→EX-FACTORY→SHIPMENT→CUSTOM CLEARANCE→A/S SERVICE FOR 1 YEAR.
