China Top Quality Transport Wood Trailer Trailers

Name: China Top Quality Transport Wood Trailer Trailers
Brand: Lufeng
SKU: 141206478
Availability: InStock

US$ 9,800 - 15,800 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

DOT

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao /shanghai

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification DOT

Size 13*2.5*1.7m

OEM No. 370811888

Max Payload 70T

Place of Origin Shandong, China

Brand Name Lufeng

Model Number LST9401TZX

wood transport trailer trailers

Product Description

Type		3axles wood transport semi trailer
Shipping Terms		Shipping by containers
Delivery time		13 workdays for one set drop side semi trailer
Weight:
	Tare Weight	7000kg
	Loading Capacity	20--70T
Specification:
	Axle number	3 pcs
	Axle specs.	FUWA 13T/16T
	Suspension
	Wheel	12.00R20
	King Pin	JOST 50# traction pin
	Dimensions (LxWxH)	13000×2350*3980mm,
	Support legs	28Tons (Tongyada Brand)/Jost D200T
	Rim	8.5-20 Zhengxing Brand
	Wheelbase	7850+1310+1310mm,
	Steel Spring	10/10/10 pieces per axles
Tire:
	Number of Tire	12 pieces
	Spare Tire Carriers	2 pieces
Frame: (specs. and materials)
	The material of Main beam	The height of the beam is 500mm,upper plate is 14mm,down plate is 16mm,middle plate is 8mm.If choose the SSAB high stress steel ,the uper and down plate is 8mm,middle plate is 5mm.
	Side board	The height is from 600-1500mm ,
	Platform plate	3mm Diamond Plate
Brake:
	Brake	Kemi Brand of China
	Brake Chamber	Four double and two single chamber( TKL brand )
	ABS system	without
Electrical:
	Voltage	24V
	Receptacle	7 ways(7 wire harness)
Light color:
	Side marker lamp	Orange
	Rear lamp	Red
	Turn signal lamp	Orange
Miscellaneous:
	Painting	According to the requirement of the buyer
	Marking	According to the requirement of the buyer
	Side Guard	According to the requirement of the buyer
	Tools box	One pieces or According to the buyer
