Home > Products > Skeleton semi trailer > Factory Price 3 Axles 40 ft Skeleton Container Trailer , 20 ft Skeleton Semi Trailer Container Chassis
Factory Price 3 Axles 40 ft Skeleton Container Trailer , 20 ft Skeleton Semi Trailer Container Chassis
- 1000 Set / Sets per Month
- Qingdao
- T/T Credit Card
- Sedan SUV transport semi-trailer export semi-trailer Russian European style semi-trailer
- Low flatbed semi-trailer Hydraulic ladder semi-trailer Automatic low flatbed export trade
- Exporting trailers to Russia European style car transport Semi trailer price
- Multi axles modular low bed semi trailer
- AUTONE wingspan van semitrailer
- Container Semi Trailers
Product Details
Type: | Semi-Trailer | Material: | Steel | Certification: | DOT |
Size: | 12.5*2.45*1.51m | OEM No.: | 37081198902 | Max Payload: | 30.48T |
Place of Origin: | Shandong, China | Brand Name: | LUFENG | Model Number: | LST9350TJZG40 |
Product Description
Factory Price 3 Axles 40 ft Skeleton Container Trailer ,
20 ft Skeleton Semi Trailer Container Chassis
Gross Weight | 5-8 tons semi trailer |
Outer side dimension (mm) | 12450 × 2490 × 1557 (three or two axles) 40FT 7160 × 2490 × 1557 (two axles) 20FT truck semi trailer |
Loading Capacity (Ton) | ≤ 45 T (40FT) ≤30T (20FT) container trailer |
AXLES | 13 T /PER , FUWA Brand, BPW Brand, or Huajing Brand |
Tire | 12.00R22.5 or 1100R20 China Brand or According to Customer requirement truck semi trailer |
Rim | 9.00-22.5 China Brand semi trailer |
Suspension | Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand ) |
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type |
Support leg | JOST brand D200T or China brand 28Tons (Double speed) |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm ; Material is Q345B Steel . truck semi trailer |
Side beam | 16mm or 18mm channel steel ( Material is Q235steel ). container trailer |
Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); one piece of 45L air tanks |
Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) |
Valve | WABCO valve semi trailer |
ABS | Optional semi trailer |
Light | LED light truck semi trailer |
Voltage | 24V semi trailer |
Receptacle | 7 ways (7 wire harness) container trailer |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely) container trailer (equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms: | Transport by bulk cargo carrier, RORO or 40HQ container. truck semi trailer |
Skeleton Container trailer truck semi trailer
Low bed semi trailer/Flatbed semi trailer/
Skeleton semi trailer/Fuel tank semi trailer
Bulk cement tank semi trailer/Stake semi trailer/
Side wall semi trailer/Rear tipping semi trailer
Box /van container semi trailer/Car transport semi trailer
Wood transport semi trailer/Concrete mix truck/
Full trailer/HOWO truck head
