Help CenterSide Lift Trailer for Sales Trailer Manufacturer With Good Quality
Related Products
-
Trailers With Hydraulic Lifts With Excellent QualityUS$ 9,800 - 15,800MOQ: 1 Set -
SINOTRUK Side Lift New Dumping Semi Trailer / Semi Trailer for Sale / Semi-trailer Dump TruckUS$ 12,000 - 21,000MOQ: 1 Unit
-
Three Wheels Semi Dumping Trailer And Dump Truck On SaleUS$ 12,000 - 21,000MOQ: 1 Unit
-
25~60ton Drop Side Tractor TrailerUS$ 1 - 10,000MOQ: 3 Sets
-
High Quailty Sinotruk Side Wall Semi Trailer / Transport Horse Truck Trailers for SaleUS$ 18,000 - 26,000MOQ: 1 Unit
Type |
|
Box semi trailer Loading for bulk goods |
Shipping Terms |
Shipping by bulk cargo ship, three pieces put together . |
|
Delivery time |
20 workdays for three unit semi trailer |
|
Weight: |
Loading Capacity |
50tons |
|
Tare Weight |
About 10T |
Axle Weight Load |
16T per |
|
Specification: |
|
|
Axle number |
Two , HUAJING brand |
|
Suspension |
America type Mechanical Suspension |
|
Wheel |
12.00R20 triangle brand tire |
|
King Pin |
2.00inch traction pin(Bolt connecting type)/.Jost brand |
|
Dimensions (Inner box) |
13000 x 2500 x 2500mm |
|
Support legs |
CTAC special two double speed legs |
|
Rim |
8.25-20 , |
|
Steel Spring |
90mm*13mm*10pieces |
|
Tire: |
|
|
Number of Tire |
8 pieces |
|
Spare Tire Carriers |
2 pieces (not tires) |
|
Frame: (specs. and materials) |
|
|
Platform plate |
3mm flat Platform |
|
The material of Main beam |
the height of the beam is 500mm,upper plate is 18mm,down plate is 18mm,middle plate is 8 mm. |
|
Side beam |
Upper side beam is 16# channel steel, down is 16# channel steel. |
|
Cross Beam |
Vertical corrugated board, thickness is 3mm |
|
Side board |
Three folio doors and with lock bars at each side(Thickness 2mm) |
|
Back Door |
With four pieces lock bars |
|
Upper side of box |
Without plate |
|
Brake: |
|
|
Emergency Brake Valve |
WABCO |
|
Brake Chamber |
Four double chamber(CTAC special for export type ) |
|
ABS system |
without |
|
Electrical: |
|
|
Voltage |
24V |
|
|
Receptacle |
7 ways(7 wire harness) |
Light color: |
|
|
Side marker lamp |
Orange |
|
Rear lamp |
Red |
|
Turn signal lamp |
Orange |
|
Miscellaneous: |
|
|
Painting |
Blue |
|
Marking |
According to the requirement of the buyer |
|
Side Guard |
2 piece |
|
Tools box (without Tarpaulin) |
One pieces(L x W x H:1500 x500 x 500mm)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
|
Tank body: We through transport shipment by RO-RO,IN BULKER,Container
Our factory fully customized production according to the customer demand
1.Our guarantee term is six months.
2. We will send the engineer to mend the semi trailer for free within the six months
3.We will send the accessries and tires.
Our factory workshop show :
Contact US
Contact man: Polaris Chen
Company :China Heavy-Duty Car Group
Liangshan Sitong Special Purpose Vehicle CO.,LTD
TEL: 0086-537-2882988
