IHU4808 001G 2000BZ1 6P5L UVW Servo motor rotary encoder

Specifications

IHU4808-001G-2000BZ1-6P5L UVW Servo motor encoder

Product Description

IHU4808 is a kind of Hollow shaft encoder, axis inside diameter 8 mm ¦, housing diameter 48 mm ¦, with flex bracket flange, easy for installing, low price at high performance.
Extensive to use for servomechanism, especially for servomotor.

1. ELECTRICAL SPECIFICATIONS

A). Output wave: Square wave

B). Output signals: A, B, Z, U, V, W, (Line driver output A, A, B, B, Z, Z, U, U, V, V, W, W phase)

C). Current consumption: d160mA

D). Response Frequency: 0~120KHz

E). Output phase difference: 90*

F). Supply voltage: 5V DC

G). Signal leve: LVHe85%Vcc, VLd0.3V

H). Number of pulses: 1000, 1024, 2048(2P, 3P, 4P); 2000(2P, 3P, 4P, 6P); 2500(2P, 3P, 4P, 5P, 6P)(Other number of pulse available on request)

I). Output circuit: Line driver


2. MECHANICAL SPECIFICATIONS

A). Speed without sealing: 6000rmp

B). Rotor moment of inertia: Appraisal 4.0x10-6Kgm2

C). Starting torque without sealing: d2.5x 10-3Nm (+25*C)

D). Shock resistance: 980m/s2, 6ms, 2 times each on XYZ

E). Vibration proof: 50m/s2, 10~200Hz, 2 hours each on XYZ

F). Working life: MTBFe50000h (+25*C, 2000rpm)

G). Weight: Appraisal 140g (with 0.35 meter cable)

3. ENVIRONMENTAL SPECIFICATIONS

A). Working humidity: 30~85% (No condensation)

B). Storage temperature: -40*C~110*C

C). Working temperature: -25*C~100*C

D). Protection class: IP54

About order

Important Information about Encoder Conditions

1. All of the  encoder are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The encoder guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t   o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.

Contact Us:

YUEQING YING'S IMPORT & EXPORT CO.,LTD

ADD:ROOM 601,NO.126 LIUYANG ROAD,CHAOYANG VILLAGE,LIUSHI TOWN,YUEQING CITY,

ZHEJIANG PROVINCE, 325604 CHINA

TEL: 0086-577-62791815  FAX: 0086-577-62791825             Mobile:0086-13757779011

Skype:benjaminying                                     TradeManager:yncync
