HKT56 Motor optical encoder (rotary encoder)
HKT56 Motor optical encoder (rotary encoder)
Product Description
The HKT56 series are high performance two and three channel optical incremental encoders. These encoders emphasize high reliability, high resolution, and easy assembly. Each encoder contains a lensed LED source (emitter), an integrated circuit with detectors and output circuitry, and a code-wheel which rotates between the emitter and detector integrated circuit. This index is an active high pulse that occurs once every full rotation of the code-wheel. Resolutions up to 2048 counts per Revolution are available in the two and three channel versions.
Features:
Two or three channel quadrature output with optional index pulse, TTL compatible single Ended outputs on HKT56 series, 100*C operating temperature, Easy assembly, No signal adjustment necessary, Resolutions up to 2048 counts per revolution, Maximum shaft diameter of 20mm.
Applications:
The HKT56 series provide motion detection to a very high resolution and accept a variety of shaft sizes up to a maximum of 20 mm
1. ELECTRICAL SPECIFICATIONS
A). Output wave: Square wave
B). Output signals: AB phase or ABZ phase
C). Current consumption: d40mA
D). Output current: 0~5mA
E). Response Frequency: 0~100KHz
F). Output phase difference: 90*
G). Supply voltage: 5V DC
H). Signal level: IVHe85%Vcc, VLd0.3V
I). Number of pulses: 1000, 1024, 2000, 2048(Other number of pulse available on request)
J). Output circuit: Line driver, Voltage
2. MECHANICAL SPECIFICATIONS
A). Rotor inertia of code-wheel: Appraisal 6.0x10-8Kgm2
B). Hollow shaft diameter: d20mm ¦
C). Shock resistance: 980m/s2, 6ms, 2 times each on XYZ
D). Vibration proo: 50m/s2, 10~200Hz, 2 hours each on XYZ
E). Working life: MTBFe50000h (+25*C, 2000rpm)
F). Weight: Appraisal 25g (with 0.5 meter cable)
3. ENVIRONMENTAL SPECIFICATIONS
A). Working humidity: 30~85% (No condensation)
B). Storage temperature: -40*C~110*C
C). Working temperature: -25*C~100*C
D). Weld temperature: d260*C
E). Protection class: IP50
About order
Important Information about Encoder Conditions
1. All of the encoder are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The encoder guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
Contact Us:
YUEQING YING'S IMPORT & EXPORT CO.,LTD
ADD:ROOM 601,NO.126 LIUYANG ROAD,CHAOYANG VILLAGE,LIUSHI TOWN,YUEQING CITY,
ZHEJIANG PROVINCE, 325604 CHINA
TEL: 0086-577-62791815 FAX: 0086-577-62791825 Mobile:0086-13757779011
Skype:benjaminying TradeManager:yncync
