Specifications
AF-10MR-E Cheap PLC export to UAE
| Code | Description |
| AF-10MR-E | DC12/24V, 6 points DC input 4 points relay output |
| This model is a DC/AC power supply, with digital input, 6 points AC/DC input, 4 points relay output | ||||
| Exquisite and compact design PLC --Programmable Intelligent Logic Controller (AF-10MR-E) | ||||
| Multi-functional, easy operating, convenient, easy learning | ||||
| Operation temperature -20-70 | Timers 127 | |||
| Storage/Transportation -40-70 | Counters 127 | |||
ProtectionIP20 |
Function blocks : 127 | |||
| Interference Regulation: EN55011(B Class) | RTC time intervals127 |
|||
RTC accuracy: MAX ±5S/day |
Storage capacity64K |
|||
CertificateCE |
Insulation Intensity: IEC1131 |
|||
| Installation: Use a standard DIN rail or screw for installation | Dimensions90*71*58Unitmm |
|||
| Power supply | ||||
Rated voltageAC14-20V/DC12/24V |
Main voltage operation rangeAC12-24V/DC10-28V |
|||
(Output full-load)Typical 3W |
AC/DC24V consumption Typical 125mA |
|||
| Digital input | ||||
| Signal 0DC 0-5V | Input current<0.2mA |
|||
| Signal 1AC12-24V/DC 10-24V | Input current<1mA | |||
Digital output |
||||
Output type: Relay output |
Wiring insulation: Yes |
|||
Points per set1 |
Continuous current max valueMAX 10A |
|||
| Switch frequency | ||||
| Mechanism 10Hz | Resistor load 2Hz |
|||
|
Inductive load 0.5Hz
PLC --Programmable Intelligent Logic Controller (AF-10MR-E) |
||||
