(AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC
Good quality PLC Controller AF-20MR-D with LCD
This model is a DC power supply, with 12 point DC input (analog), 8 point relay output | ||||
| Exquisite and compact design PLC --Programmable Intelligent Logic Controller (AF-20MR-E ) | ||||
| Multi-functional, easy operating, convenient, easy learning | ||||
| Operation temperature -20-70 | Timers 127 | |||
| Storage/Transportation -40-70 | Counters 127 | |||
ProtectionIP20 | Function blocks : 127 | |||
| Interference Regulation: EN55011(B Class) | RTC time intervals127 | |||
RTC accuracy: MAX ±5S/day | Storage capacity64K | |||
CertificateCE | Insulation Intensity: IEC1131 | |||
| Installation: Use a standard DIN rail or screw for installation | Dimensions90*126*58Unitmm | |||
| Power supply | ||||
Rated voltageDC12/24V | Main voltage operation rangeDC10-28V | |||
DC24V consumption Typical 200mA | (Output full-load)Typical 5W | |||
| Digital input | ||||
| Signal 0DC 0-5V | Input current<0.4mA | |||
| Signal 1DC 10-24V | Input current<1mA | |||
| Analogue input | ||||
Signal 1 0-10V | Input current<0.3mA | |||
Outputs (Digital output) | ||||
Output type: Relay output | Wiring insulation: Yes | |||
Points per set1 | Continuous current max valueMAX 10A | |||
Switch frequency | ||||
Mechanism 10Hz | Resistor load 2Hz | |||
Inductive load 0.5Hz
PLC --Programmable Intelligent Logic Controller (AF-20MR-D) | ||||
Photos of the product:
(AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC (AF-20MR-D) HMI programmable controller PLC
Important Information about PLC Conditions
1. All of the PLC are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The PLC guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
