FBs-4DA FATEK programmable controller

Specifications

FATEK FBS-4DA ,Programmable controller
1,Reasonable price and high quality,
2, Well sold in the market
3, CE RoHs certificat



Iutput: 2-point input / output values:  -8192 ~ 8191 or 0 ~ 16383 (14-bit value) input / output signal range: Bipolar: Voltage: -10 ~ 10V or -5 ~ 5V Current: -20 ~ 20mA or -10 ~ 10mA unipolar: voltage: 0 ~ 10V or 0 ~ 5V current: 0 ~ 20mA or 0 ~ 10mA finest resolution: voltage: 0.3mA (5V/16384) current: 0.61μA (10mA/16384) overall accuracy: ± 1% conversion rate: updated once per scan maximum allowable input signal: input current: ± 30mA permissible load range: Voltage output: 500Ω ~ 1MΩ current output: 0Ω ~ 500Ω input impedance: No isolation: Transformer (power) and coupler (signal) isolation is no isolation between the input CH power: 24VDC 15% / 20%, 2VA max wiring body: 7.62mm fixed terminal block l 4 D / A output module form factor: Extended module: 1FBS-8E , FBS-7SG, FBS-6AD, FBS-2DA, FBS-4DA, FBS-4A2D, FBS-TC2, FBS-TC6, FBS-RTD6, FBS-CM5H, FBS-2ATC4, FBS-2ARTD4 2FBS-24EX, FBS -24EYT, FBS-32DGI * (1,2 are two types of module base sharing, different cover, cover icon cover class 1)
These are the FBS-4DA analog output module for more information if you are FBS-4DA analog output module price, make, model, pictures have any questions, please contact us for FBS-4DA analog output modules to-date information.
