LC1D12 AC Contactor Magnetic Contactor (Motor Protective Contactor)

           A corresponding, LC1 is (CJX2, CJX4) series of AC contactor (hereinafter referred to as the contactor), mainly used for AC 50 hz or 60 hz, AC voltage to 660 v, 690 v), used in AC - 3 categories under working voltage is 380 v, rated current 170 a circuit, for long-distance connected and breaking circuit, and can be combined with the corresponding specifications of the thermal relay into magnetic starter may occur in order to protect the load circuit, contactor is suitable for frequent starting and control of AC motor.

The contactor and LC1, LC2, LP1, LP2, CJX4 - D has a corresponding specification can be equal to each other using the same function.Is the ideal replacement CJ0, CJ10 old products.

 The normal working conditions and installation conditions
1, the ambient air temperature is: - 5 °C ~ + 40 °C, no more than 24 hours the average + 35 °C;
2, altitude: not more than 2000 m;
3, atmospheric conditions: when + 40 °C air relative humidity is no more than 50%, at low temperature can be high relative humidity, the wettest month average minimum temperature is not more than + 25 °C, the mean monthly maximum relative humidity is not more than 90% of the month.And consider on condensation due to temperature changes occur in the product;
4, pollution level: level 3;
5, installation category: Ⅲ classes;
Mounting surface and vertical gradient of the 6, installation requirements: not more than + / - 5 °;
7, impact vibration: the product should be installed and used in no significant shake, impact and vibration.
8, installation method: contactor in addition to use screw to install, still can use 35 mm, card type standard rail installation.Communication operation 40-95 use 35 mm or 75 mm card rail installation;
Note: 40-95 dc operation can only use 95 mm card rail, 115-170 have a special card rail installation.

Important Information about contactor Conditions

1. All of the contactor are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The contactor are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t   o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
