Home > Products > Other Products > LM18-3005PC Dc NO NC PNP M18mm inductive proximity switch sensor wireless motion sensor hidden camera
LM18-3005PC Dc NO NC PNP M18mm inductive proximity switch sensor wireless motion sensor hidden camera
- 100000 Piece / Pieces per Month
- Shanghai
- Credit Card
Product Details
| Brand Name: | YUMO | Model Number: | LM18-3005PC | Usage: | Position Sensor |
| Theory: | Inductance Sensor | Output: | Analog Sensor |
Product Description
LM18-3005PC Dc NO NC PNP M18mm inductive proximity switch sensor wireless motion sensor hidden camera
Specifications
Proximity switch LM18-3005PC
1.CE approved
2.inductive switches, proximity principle, proximity probe, proximity switch
3.Detection distance:5mm or 8mm
| INDUCTIVE PROXIMITY SWITCH(inductive switches, proximity principle, proximity probe, proximity switch,inductive proximity switches) | |||||
| Outward appearance code | LM18 | ||||
| Flush | Detection distance | 5mm | |||
| NPN | NO | 3005NA | |||
| DC | NC | 3005NB | |||
| 6 | NO+NC | 3005NC | |||
| PNP | NO | 3005PA | |||
| 36 | NC | 3005PB | |||
| V | NO+NC | 3005PC | |||
| two wire system | NO | 3005LA | |||
| NC | 3005LB | ||||
| AC | SRC Control label silicon | NO | 2005A | ||
| 90 | NC | 2005B | |||
| 250 | NO+NC | 2005C | |||
| V | Relay output | ||||
| Non-flush | Detection distance | 8mm | |||
| NPN | NO | 3008NA | |||
| NC | 3008NB | ||||
| DC | NO+NC | 3008NC | |||
| 6 | PNP | NO | 3008PA | ||
| NC | 3008PB | ||||
| 36 | NO+NC | 3008PC | |||
| V | two wire system | NO | 3008LA | ||
| NC | 3008LB | ||||
| AC | SRC Control label silicon | NO | 2008A | ||
| 90 | NC | 2008B | |||
| 250 | NO+NC | 2008C | |||
| V | Relay output | ||||
| Control output | DC | 200mA | |||
| SCR/Relay | 300mA | ||||
| Output voltage dropDC/AC | DC<3V AC<10V | ||||
| Consumption current | DC<15mA AC<10mA | ||||
| Standard detected object | 18×18×1(A3 iron) | ||||
| Repeated precision | 0.02 | ||||
| DC/AC Response frequency | 200Hz/25Hz | ||||
| Working environment temperature | 2575 | ||||
| Insulation resistance | 50MΩ | ||||
| Shell material | Metal | ||||
| Protection grade | IEC standard IP67 | ||||
| Altemative model at home and abroad | LJ18A3-18- | ||||
