YUMO JS16B-10/J/N momentary metal push button switch
The front Shape: Domed
Terminal Type: Pin Terminal(2.8×0.5mm)
Switching: No.1
Max.Switch Rating: 2A/36VAC
Contact Resistance: ≤ 50mΩ
Insulating Resistance: ≥ 1000MΩ
Dielectric Strength: 2000VAC
Operating Temp: -20oC~+50oC
Mechanical Life: 100,000 cycles
Electrical Life: 200,000 cycles
Panel Thickness: 1~6mm
Tortque: 5~14Nm
Operation Pressure: About 4N
Operation Distance: About 1.5mm
IP Degree: IP65
Contact Material: Silver Alloy
Button Material; Stainless Steel
Body Material: Stainless Steel(Chromium plated,gold plated)
Base Material: PBT
1 . 16mm diameter
2. Switch Rating : 2A/36V
3. Operation Type : Momentary
4. The Front Shape: Domed
5. The Crust Material: stainless steel/Brass(Chromium plated,Gold Plated)
6. Contact Configuration: 1NO
7. IP Degree: IP65
YUMO JS16B-10/J/N momentary metal push button switch YUMO JS16B-10/J/N momentary metal push button switch YUMO JS16B-10/J/N momentary metal push button switch YUMO JS16B-10/J/N momentary metal push button switch YUMO JS16B-10/J/N momentary metal push button switch YUMO JS16B-10/J/N momentary metal push button switch
