Human Machine Interface MT6070iH 7 Inch HMI

Name: Human Machine Interface MT6070iH 7 Inch HMI
Brand: YUMO
SKU: 141202456
Availability: InStock

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-1

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-2

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-3

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-4

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-5

Human Machine Interface MT6070iH 7 Inch HMI thumbnail-6

Human Machine Interface MT6070iH 7 Inch HMI photo-1

Human Machine Interface MT6070iH 7 Inch HMI photo-2

Human Machine Interface MT6070iH 7 Inch HMI photo-3

Human Machine Interface MT6070iH 7 Inch HMI photo-4

Human Machine Interface MT6070iH 7 Inch HMI photo-5

Human Machine Interface MT6070iH 7 Inch HMI photo-6

US$ 180 - 250 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

YUMO

Model Number:

MT6070iH

Contact Supplier Request Quote Chat Now

Yueqing Yings Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name YUMO

Model Number MT6070iH

Type TFT

Human Machine Interface MT6070iH 7 inch HMI

Product Description

Display

Display:	7" TFT LCD
Brightness (cd/m2):	375 cd/m2
Contrast Ratio:	500:1
Color:	65536
Resolution (WXH):	800x480
Back Light:	LED
Back Light Life Time:	30,000 hr

Touch Panel

Touch Panel Type:

4 wires resistive type

Memory

Storage (RAM):	128
RAM (RAM):	64

I/O ports

SD Card Slot:	N/A
USB Host:	USB 1.1 x 1
USB Client:	USB 2.0 x 1
Ethernet Port:	N/A
COM Port:	COM1(RS232 / RS485 2W/4W),COM2(RS232) COM3(RS232/RS485 2W)
Audio:	N/A

Power

Input Power:	24 ±20% VDC
Power Consumption:	250mA@24VDC

Working principle:
1. The use of pressure sensing control.
2. The main part is a very cooperate with the resistance of the film screen and display surface, this is a kind of multilayer composite films, with a layer of glass or hard plastic plate as a base, surface coated with a layer of transparent metal oxide transparent conductive resistance of the conductive layer, the above with a layer of surface hardening treatment, smooth and rubbing of the plastic layer, the inner surface is coated with a layer of coating, among them there are many small (less than 1/1000 of an inch) of transparent isolation point separates two conductive layer of insulation.
3. When the finger touching the screen, two conductive layers in touch point location had contact, resistance to change, produced in the X and Y directions signals, then send a touch screen controller.Controller to detect the contact and to calculate the position (X, Y), according to simulation the mouse operate.

Human Machine Interface MT6070iH 7 inch HMI Human Machine Interface MT6070iH 7 inch HMI Human Machine Interface MT6070iH 7 inch HMI Human Machine Interface MT6070iH 7 inch HMI Human Machine Interface MT6070iH 7 inch HMI

About order

Important Information about hmi Conditions

1. All of the hmi are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The hmi are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
