HMI (Human machine interface)7" TFT LCD touch screen MT8070iH with ethernet port
Specifications
weinview HMI 7" 800*480 TK8070IH Stock New
Descriptions:
MT8000 series is the new HMI generation of Weintek. With the design concept of meeting customers’ satisfaction while easy-to-Use attribute as before, a MT8000 not only performs as a Human Machine Interface but also plays as a role of data exchange center. Through the most popular Ethernet connection, data can be shared among MT8000s without limitation and any SCADA/HMI software on the PC can simply access data from MT8000s.
Specifications | |
Display |
7" TFT |
Brightness |
350 cd/m2 |
Color |
65,536 colors |
Contrast Ratio |
550:1 |
Resolution (W x H dots) |
800 x 480 |
Back Light |
LED |
CCFL Life Time |
30,000 hr. |
Touch Panel |
4 wires resistive type |
Touch Accuracy |
Active Area Length(X)±2%, Width(Y)±2% |
Surface Hardness |
4H |
I/O port |
COM1 (RS-232/RS-485 2W/4W), COM2(RS232), |
USB Host |
1 USB 2.0 Full Speed Host port |
Audio |
1 x Audio Line Out, 1 x MIC In |
Processor |
32bit RISC CPU 400MHz |
DRAM |
128MB 64MB DDR2 RAM |
RTC |
Built-in (CR2032 3V lithium battery backup.) |
General Specification | |
Input Power |
24±20% VDC (Power Isolator Inside.) |
Power Consumption |
1.6 A@24VDC |
CE |
Complies with EN50081-2 and EN50082-2 standards |
FCC |
Complies with FCC Class A |
Voltage Resistance |
500VAC (1 min.) |
Isolation Resistance |
Exceed 50Ω at 500VDC |
Vibration Endurance |
10 to 25 Hz (X,Y,Z direction 2G 30mins) |
Protection Structure |
IP65 front panel (O ring seal) |
Operating Temperature |
0~45°C |
Operation Humidity |
10-90% RH (non –condensing) |
Enclosure |
Aluminum |
Dimensions WxHxD |
200 x 146 x 41.8mm |
Panel Cutout Dimensions |
192 x 138 mm (7.5"x5.4") |
Weight |
Approx. 0.7 kg |
Operating System | |
Operating System |
EB8000 V4.42 or Newer |
Important Information about HMI Conditions
1. All of the hmi are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The hmi are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
