JDM12 Counter

Yueqing Yings Import & Export Co., Ltd.
JDM12 Counter thumbnail-1
JDM12 Counter photo-1
US$ 0.5 - 5.5 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
JDM12
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number JDM12
Theory Solid State Relay
Usage General Purpose
Size Miniature
Protect Feature Sealed

Specifications

JDM12 Counter



  JDM12 Counter

Specifications

JDM15/12/TCN series Digital-display Counter
JDM12
Randomly set plus, minus, random reversible five input modes





Summary
JDM15/12/TCN series is a new generation and small volume counter produced by our company, it adopts latest style monolithic microcomputer with excellent performance as primary control unit, it has merits of high precision, wide range counting digital, display , strong anti-jamming performance and beautiful looking etc. This series electronic counter is widely used for counting display, counting control in fields such as packing, printing, pharmacy, food, textile, paper making, ceramic,petroleum, chemical industry and metallurgy etc, and also can be used for display and autocontrol of parameter like revolution , length and so on. It is quite popular among customers and has already been quipped for export.







Applicable Scope

1.DIN 72×72mm outline panel size
2.5/6 preset digits, and 2 digits firing lead is set
3.Randomly set plus, minus, random reversible five input modes
4.N,F,C,R four work modes
5.Power off memory
6.Max. counting speed 1000times/sec.
7.Directly connecting with photoelectric,approaching switch or contact signal
8. Suitable for control of automatic coil winding machine





Technical Data

Power supply: AC 220V 50/60Hz
Voltage range: 85%~110%Ue
Counting range: 0~99999
Firing lead:0~99
Max. counting pulse width:
16.7mS( low speed≤30 times/sec)
0.5mS (high speed ≤1000 times/sec.)
Input signal: 1.no contact signal ntact signal
Signal input impedance: ≥4.7KΩ
Input signal voltage : L=0~2V H~30V
Weight: around 0.4kg
Relay input : preset 1 group 3A AC220V(resistance per
formance)firing lead 1 group 3 groupes AC220V
(resistance performance)
Contact mechanical endurance: ≥ 105
Contact electrical endurance: ≥ 105
Cuxiliary power supply output: DC12V 30mA(max) may supply
for sensor use
Reservation for power off: ≥5 years
Power consumption: ≤5VA
Reset mode: start reset(when no reservation for power off ) panel
button reset(0.1~3 secs. regulable) external terminal reset
Holing dimension: 68×68mm



JDM12 CounterJDM12 Counter
