Home > Products > Drip irrigation pipe machinery > Drip irrigation Pipe production line with Flat Dripper, 180m/min, drip irrigation pipe
Drip irrigation Pipe production line with Flat Dripper, 180m/min, drip irrigation pipe
USD $160,000 - $300,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Qindao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition: | New | Application: | Pipe | Plastic Processed: | PE |
Screw Design: | Double-screw | Automatic Grade: | automatic | Place of Origin: | Shandong, China |
Brand Name: | Zeanon | Model Number: | SJSZ65/132 | Voltage: | 380V |
Power(W): | 37kw | Dimension(L*W*H): | 20mx2.5mx2.2m | Weight: | 20T |
Certification: | ISO9001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Drip irrigation Pipe production line with Flat Dripper
High-speed automated screening and embedding system
- With slight adjustment,the screening and embedding system then can be used foridentification and transportation for single-hole dripper,middle-hole dripper and double-hole dripper.
- The system has special designed identification device that can provide 100% dripper passing guarantee.
- Identification speed>600pcs/min.
- Dripper embedded space:between 100-1500mm,the dripping hole space can be adjusted through the PLC interface.
Automatic punching technology and online monitoring system
- Own National invention patent(National Patent No:ZL200710063376.7)
- High-speed for punching single hole,middle hole and double hole.Speed>800 times/min.
- Configured with two alarm system for addident skipping and spacing deviation identify.
- Configured with high-speed camera and PLC interface operating interface for tracking,monitoring and record storage.
Automatic rewinding and metering functionality
- It is used by servo motor drive.
- Automatic completion for dripper winding displacement,cutting and metering.
- Very simple PLC operating interface for winding speed and roll volume control.
Item | Pipe diameter | Pipe thickness | Production speed | Distance of dripper |
Flat dripper irrigation pipe production line | Φ12-16-20mm | 0.18-0.9mm | 150m/min | 100150200300400500-1500mm |
