Specifications
1) Lighting Tower Generator2) 7m/9m mast,powered by kubota engine
3) 4pcs/6pcs X 1000W lamps
4) hydraulic / manual operation
Lighting Tower Generator
Feather and benefite:
This is the most advanced winch-operated light tower in the market. It consists of an extra heavy-duty trailer, four floodlights and diesel-driven generator set
mounted in a weatherproof enclosure for extra wild operation protect.
Features:
1) Consists of an extra heavy-duty trailer, four floodlights and diesel-driven genset
2) Single, hand-operated safety winch
3) Operator control and troubleshooting are easier with centralized control panel
4) Weatherproof enclosure for extra wild operation protect
5) Rugged floodlight fixture with lamp-end support
6) Tilt spring starts tower toward travel position when lowering
7) Extra heavy-duty trailer frame
8) Long-lasting automotive finish
9) An extra 80L fuel tank provides up to 50 hours operation
10) Single-points lifting eye and tie-down rings
11) The output of the tower is below 20kW
| STANDARD Eqyuipment | 4TL4000 | |||||||
| LENGTH(MM) | 4600(3100,Dismantling the tow bar) | |||||||
| WIDTH(MM) | 1500 | |||||||
| HEIGHT(MM) | 1850 | |||||||
| MAST HEIGHTH(M,full extended) | 9 | |||||||
| Weight(wet) | 890kgs | |||||||
| Engine model | D1105-BG(Kubota) | 3TNV76(Yanmar) | perkins engine | 380(Lester) | ||||
| Frequency(HZ) | 50 | 60 | 50 | 60 | 50 | 60 | ||
| Speed(rpm) | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 | ||
| Continued Power(kva) | 7 | 9 | 7 | 9 | 7 | 9 | ||
| Number of Cylinders | 3 | |||||||
| Diesel Engine Characters | 4ycle in line ,Watercooled diesel | |||||||
| Combustion Type | Precombustion | Direct Injection | Indirect Injection | Direct Injection | ||||
| Engine Aspiration | Natural | |||||||
| Emission Level | Stage3 | Tier4 | Stage3 | Tier4 | Stage2 | Tier4 | N.A | Tier4 |
| Alternator | Brushless&Single phase | |||||||
| Rating Voltage(v) | 230 | |||||||
| Alternator Insulation , | H | |||||||
| Fuel Tank Capacity | 95 liters(25 US Gallons) | |||||||
| Fuel Tank Operating Hours | 60 hours | |||||||
| Type of Lights | Metal Halide Spotlight(Local Brand) | |||||||
| Number &Power of Lights | 4x1000W | |||||||
| Mast Lifting & Extension | Manual operation | |||||||
| Mast Rotation | 359 Manual operation | |||||||
| Light bar Tilt | Manual operation | |||||||
| Stabilizing Legs | Manual operation | |||||||
| Trailer suspension System | Steel plate spring | |||||||
| Hitch | Ball or O ring | |||||||
| Tire Rim Size | 14" | |||||||
| Acoustic Pressure | 75dB(A) at 7 meters away | |||||||
| Max.load quantity in a 20'container(sets) | 6 | |||||||
