Plastic pipe machine: PVC Pipe Making Machine

Specifications

1.raw material:PVC
2.screw type:conial twin-screw
3.reliable performance
4. efficient









This production line is mainly used to produce all kinds of PVC pipes, which are widely used in water supply and drainage of agriculture land and construct, and cable laying. This production line is composed of conical(parallel)twin-screw extruder, headpiece, vacuum sizing device, traction machine,cutting machine and roll-over stand. The extruder and traction machine adopts frequency control. The traction machine can be with two, three, four, six and eight claws. This production line  is equipped with cutter(saw web or planetary).The production line has reliable performance and high efficacy.



Main technical parameters:



Specifications of the unit	GF125	GF160	GF250	GF500	GF630
Max. dia. of the tubular products Φ	125	160	250	500	630
Total power of the auxiliary machine Kw	13	14	19	27.5	35
Volume of cooling water m3	3	6	6	9	12
Pressure of the compressed air MPA	0.6	0.6	0.6	0.6	0.6
