Specifications
v conveyor belt machine1. good output
2. high efficiency
3. simple operation
Main technical paremeters
Models | SM DGD 50/50 | SM DGD 55/55 | |
Models | SJ-50/30×2 | SJ-55/30×2 | |
Screw diameter | Φ50 | Φ55 | |
L/D | 30 | 30 | |
Rotating speed | 90R/Min | 100R/Min | |
Total heating power | About 18kw | About 19.5kw | |
Central height | 810mm | 400mm | |
Main motor | 15kw (4 grade)×2 three phase asynchronous motor + frequency control | 15kw (6 grade)×2 three phase asynchronous motor + frequency control | |
Gear box | GB-146×2 | GB-173×2 | |
Die head | Φ55 double-layer | Φ55 double-layer | |
Traction device | Traction mode | Four-roller type | |
Traction motor | three phase asynchronous motor | ||
Speed control mode | Frequency control | ||
Motor power | 0.75kw | 1.1kw | |
Reducer model | WPA60 | ||
Max. traction speed | 40m/min | 55m/min | |
Mould wheel | Motor | 0.75KW | 1.1KW |
Motor ratio | 60:1 | 40:1 | |
Dia. of wheel | Φ477.2 or Φ451 | Φ477.2 | |
Emitter space | 150, 200, 250, 300, 400, 500, 600 mm etc (customer selected) | ||
Flow rate | 1.2L/H---4.5L /H (customer selected) | ||
Coiling device | Coiling mode | Two-position | Three-position |
Motor | Torque motor 6/6N.M | ||
Central height | 112mm | ||
Electrical cabinet | 11 sections temperature control | 11 sections temperature control | |
Frequency converter | |||
Line speed | 30m/min ×2 | 45m/min×2 | |
