High-quality Strong Power Agricultural Film Machine Set
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, agricultural film
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3FM5000-IV Plastic Greenhouse Blow Film MachineNegotiableMOQ: 1 Set -
3FM5500-I Hdpe Ldpe Lldpe Film Manufacturers Plastic Greenhouse Film Machine SetNegotiableMOQ: 1 Set
-
PE WIDE WIDTH MULCH FILM MAKING MACHINENegotiableMOQ: 1 Set
-
Two Colors Film Successions Blowing PlantNegotiableMOQ: 1 Set
-
Everflying Two Colors Film Trains Film Blow Molding MachineNegotiableMOQ: 1 Set
Condition
New
Product Type
Other, agricultural film
Place of Origin
Shandong, China
Brand Name
Hengxiang
Model Number
LD100/LD1300/LD1600/LD2200/LD2500/LD2650/LD2800
Voltage
380V
Certification
ISO9001
Warranty
six months
After-sales Service Provided
Overseas service center available
Specifications
LD series agricutural film blowing machine is applicable for producing agricutural film of LDPE,LLDPE,and LLDPE/LDPE blend.»Features amd application
1. The die head adopts advanced central head feeding spiral runner molding technology.
2. Molding and cooling of the film adopts air blower and air ring with high-property ,low air pressure, and large air volume.
3. The extruder adopts corrugated screw with oblique barrier and mixing head,which assures stable and reliable performance, high output and low energy consumption.
4. It adopts friction type double surface wind-up, which has improved the flatness of the film,and made the coiling structure tight. It is easier to operate. A length metering device is intalled, which makes the length of the film is accurate.
5. The electrical components are domestic fanous brand, which realizes one panel control.
Technical parameters
| Model | LD1100 | LD1300 | LD1600 | LD2200 | DD2500 | LD2650 | LD2800 |
| Max.folding width of film(mm) | 1,000 | 1,200 | 1,500 | 2,000 | 2,300 | 2,500 | 2,600 |
| Max.folding width of film (mm) | 800 | 1,000 | 1,300 | 1,800 | 2,100 | 2,300 | 2,400 |
Ground film thickness (mm) | 0.003-0.009 | ||||||
| Farm film thickness (mm) | 0.04-0.08 | ||||||
| Outputs(kg/h) | 50 | 52 | 110 | 130 | 180 | 220 | 240 |
| Applicable meterial | LDPE,LLDPE,LDPE/LLDPE Blend | ||||||
| Screw diameter (mm) | 45 | 50 | 65 | 75 | 75 | 90 | 90 |
| L/D of screw | 30 | 28 | 28 | 28 | 30 | 30 | 30 |
| Max. rotating speed of screw | 130 | 130 | 140 | 105 | 110 | 120 | 120 |
| Type of the main motor | Can be matched by the requirements of the customer | ||||||
| Power of main motor(KW) | 15 | 18.5 | 37 | 45 | 55 | 75 | 90 |
| Die head type | Spiral die head | ||||||
| highest speed for ground film coiling(m/min) | 120 | 120 | 120 | 120 | 100 | 80 | 80 |
| highest speed for farm film coiling(m/min) | 30 | ||||||
| Total power | 28 | 32.5 | 72 | 80 | 88 | 105 | 180 |
| Overall dimensions(m) | 6.2×2.3× 5 | 6.4×2.5× 5 | 6.6×3 × 6.8 | 7.5×2.5× 7.7 | 7.8×3.2× 10.5 | 8×3.5 × 10.5 | 13×4× 9 |
| Weight(Tons) | 5.2 | 5.5 | 6.5 | 8.5 | 16 | 19.5 | 21 |
