Help Center300A-700A Diesel Welding Machine Generator
Related Products
Specifications
1)Diesel Welding Machine Generator2)Rated Welding Current:600A
3)Lifetime Service
4)Duty Cycle:60%
5)2Years Warranty
1, Diesel Welding Machine Generator Information,
Welding Generator |
DC or AC |
Welding Current |
50A-600A |
Type |
Both Welding and Generating |
Rated Voltage |
400/230v, 415/240v, 380/220v, 220/127v, 220/115v.
|
Rated Frequency |
50/60HZ
|
Phase |
1 phase and 3 phase |
Duty cycle |
60% |
Steady Voltage Regulation |
within ±1% |
Transient Voltage Regulation |
-15 to +20% |
Steady Frequency Regulation |
±3% |
Transient Voltage Recovery Time |
≤1s |
Voltage Fluctuation (Tolerance) |
within ±0.5% |
Voltage Waveform Distortion |
≤2.5%
|
Voltage Unbalance Under Unbalanced Loads |
≤;3% |
Insulation |
Class H (125K) |
Generator Type |
Open Type, Weatherproof/Soundproof, Automatic Type or Mobile Trailer Type |
Engine Brand |
Cummins/Perkins/Deutz/Ricardo |
Alternator Brand |
Brushless |
2,Characteristics and uses
It adopts MOSFET invert technology, high frequency arc start design.
It can balance automatic when voltage is waving, with high resist to electrical wave (V15%).
It has high efficiency, small unload loss, save over 40% than the traditional welder.
It is small and light, easily work in high altitude.
It is easily arc, small flash, low noise, stable welding arc, wonderful welding shape.
With inner stalling protective circuit of over-heat, over-current, over-voltage and under-voltage. working safe is reliable.
3,Generator Set information,
Prime/Rated Power Output: 10kw/12.5kw-50kw/62.5kva.
Standby Power Output: 11kw/13.75kva-55kw/68.75kva.
Rated Frequency: 50/60hz.
Rated Voltage:Frequency at 50Hz: Available in 400/230v, 415/240v, 380/220v, 220/127v,220/115v.
Frequency at 50Hz: Available in 480/227v, 440/254v, 220/117v,208/120v. DC type.
Phase: 3 Phase and 1 phase.
Both Generating and Welding.
Welding Current:200A-500A.
Duty Cycle:60%
4,General Features,
Universal design and manufacture
Most wildly used around the world
With most service terminals
You can find spare-parts very easy.
5,Engine Information,
Diesel Engine: Perkins Diesel engine, Cummins Diesel Engine, Deutz Diesel Engine, Ricardo Diesel Engine, and other Chinese brands diesel engine.
6, Alternator Information,
Stamford, Marathon, Leory Somer and other Chinese good brand.
7,Electrical Specifications
Power Factor:0.8 Lagging
3 Phase 4 Pole
Insulation: Class H
Brushless
Self-Exited
IP22 Protection
AVR regulation
Starting by Battery
8,Special Type Generator Set
Acoustic Soundproof Generator Set
Containerized Generator Set
Trailer-Mounted Generator Set
Mobile Generator Set(Truck Mounted)
Automatic(With AMF and ATS Panle)
9, Warranty Information,
Guarantee Peried: 2 years or 2000hours whichever comes first.
During the guarantee peried, the spare-parts will be sent through your shipping agency in China.
Spare-parts can also be sent throught FEDEX or DHL, but the shipping cost will be charged.
24 hours service hotline is alvailable for customers.
We will supply Full Life Technical Consultation at any time free of charge.
