200kw Natural/Bio Gas Generator Set 10-250kw

200kw Natural/Bio Gas Generator Set 10-250kw thumbnail-1
200kw Natural/Bio Gas Generator Set 10-250kw photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Huatian
Model Number:
200GFT
Contact Supplier Request Quote Chat Now
Weifang Huatian Diesel Engine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Huatian
Model Number 200GFT
Output Type AC Three Phase
Speed 1500/1800RPM
Frequency 50/60Hz
Rated Power 200kw
Rated Voltage 400/230V
Rated Current 361A

Specifications

1)natural gas generating set 4 hrs test
2)1year or 2000hrs warranty
3)Stamford or Siemens alternator
4)cheaper energy...

ENGINE
 Model 200GFT
engine model 12V138ZQ
Rated output (kw) 230
Starting method Electric starting
Cooling method Closed water cooled
Intaking method Natural spirated
Cylinder number 12
Fuel consumption (g/kw.h) 0.33m³/kw.h
Bore*stroke (mm) 138*130
Type Water cooling,In-line,four-stroke,direct injection,
Crankshaft rotation direction counter clockwise(face to the output end)
GENERATOR Model 200GFT
Rated output(kw)(KVA) 200(250)
Rated Voltage (V) 400/230
Rated Current (A) 361
Frequency (Hz) 50
Power Factor 0.8
Electrical starter(V) 24V
Exciting method Brushless
Insulation class H
Protection degree IP23
Phase/Connection 3-phase   Y-type comnnection
Excitation Brushless Excitation
packing size LWH(mm) 2750*1300*1800

Natural gas generator set

1)      Whether the Gas Generator is suitable for you to adopt or not?

a.       Energy cost takes a comparatively large proportion in production costs.

b.       The local government has strict requirements and management on pollution.

2)      Characteristics of Gas Generator:

a.       Gas Generator can replace commercial power, and used as prime power of town and country.

b.       Making the best use of cheap energy, reduce your energy, production and living cost effectively.

3)      Comparison between Gas Generator and other Energy Supplied Generators(for example, Diesel Generating Set)

4)      Gas Quality Standard of Gas Generator

Gas Type

Chemical Formula

Restricted Standards

1

Methane Value

CH4

More than 65%

2

Ethane

C2H6

less than 6%

3

Hydrogen

H2

less than 0.2%

4

Propane

C3H6

less than 2%

5

Butane

C4H10

less than 0.2%

6

Other Segregation of Hydrocarbons

CXHY

less than 2%

7

Sulfureted Hydrogen

H2S

less than 0.01%

8

Flammable Substance



less than 85%

Remark: 1. Gas pressure is between 5 to 10kpa

       2.The lowest thermal value is 34.7MJ/m³



5) Main Advantages of Gas Generators

a. Adopting famous brand gas engines and alternators at home and abroad.

    Engine: HUATIAN

    Alternator: Stamford, Marathon, etc.

    b. Introducing the most advanced fuel gas electronic control technology, this takes full advantage of gas.

    c. Adopting advanced ignition system to ensure humanization of ignition control.

    d. Low-pressure gas intake guarantees the safety of gas transportation.

    e. Effective protection on exhaust system to prevent heat from releasing to generating room

    f. Computer supervisory control system realizes short distance and remote monitoring.

g. Intelligent control panel is convenient for operation.

h. Safety Guarantee Four lines of defense to ensure the safety of gas pipe.

i. Advanced factory test to guarantee the gas generator possesses high quality.

6) Gas Generator allocation of Weifang Huatian Diesel Engine Co., Ltd.

      Standard Allocation Optional Allocation

      HUATIAN Gas Engines Multifunction Control Module

      Stamford, Marathon, Series Alternators Automatic

      Transfer Device

      Digital Control Module Wrong Combustion Prevention Device

      Gas Control System Heat Exchanger and Remote Radiator

      Ignition System

      Negative Booster

      Fire Arrestor

      Electric Speed Regulator

7) Generally speaking, gas generators has open type (no requirement on noise) and standard type generating rooms. Requirements of standard type generating room are as followed:

    A) Generating room requirements

    a. According to explosion prevention requirements, the closed generating room should equipped with automatic ventilation system or compulsive ventilation system......

    b. The control room and generating room should be separated, and requires proper ventilation...
