Fire Retardant Tubes, Flame Retardant Tubing ASR1026

Name: Fire Retardant Tubes, Flame Retardant Tubing ASR1026
Brand: Xindong
SKU: 141183074
Availability: InStock

US$ 0.12 - 0.28 MOQ: 1000 Meters

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Xindong

Model Number:

ASR1026

Dongguan Xindong Rubber Plastic & Hardware Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Xindong

Model Number ASR1026

Specifications

Flame Retardant Tube
1.Approval: ROHS
2.Common wall thickness: +/-0.2mm
3.Operating Temperature: -60C~+250C
4.Retard Fire

Fire Retardant Tubes, Flame Retardant Tubing

1. Approval: ROHS Black Rubber Foam Insulation Tubes

2. Common wall thickness: +/-0.2mm

3. Operating Temperature: -60C~+250C

The Silicone Rubber Tube of heat resistance is also called Flame Retardant Silicon Rubber Hose, which consists of Extrusion Tube and Special-shaped Tube or Strip. The Flame Retardant Silicon Rubber Hose is made by Common Silicone Rubber which refined into double roll mixing machine or closed kneading machine together with flame retardant. As the flame retardant grade, the Flame Retardant Silicon Rubber Hose is divided into UL94HB, UL94V2, UL94V1, UL94V0 and DIN5510.
Item	Unit	Test Standard	Targeted Value
Hardness	HA	GB/T 6031-1998	50-80
Appearance			White or grey
Proportion(25°C)	g/cm3	GB/T 533-1991	1.15-1.26
tensile strength	MPa	GB/T 528-1998	6.5-8.5
elongation at break	%	GB/T 528-1998	≥180
tensile set	%	GB/T 528-1998	6.0-8.0
tearing strength	kN/m	GB/T 529-1999	≥9
Temperature Renge	°C		-60°C-200°C

Specifications:

Size	Diameter		Thickness
Size	I.D.	O.D.	Standard	Minimum
0.8*1.8	0.8±0.1	1.8±0.1	0.5	0.38
1.0*2.0	1.0±0.2	2.0±0.2	0.5	0.38
1.2*2.2	1.2±0.2	2.2±0.2	0.5	0.38
1.5*2.5	1.5+0.4/-0.2	2.5+0.4/-0.2	0.5	0.38
2.0*3.0	2.0+0.4/-0.2	3.0+0.4/-0.2	0.5	0.38
2.5*3.5	2.5+0.4/-0.2	3.5+0.4/-0.2	0.5	0.38
3.0*4.0	3.0+0.4/-0.3	4.0+0.4/-0.3	0.5	0.38
3.5*4.5	3.5+0.4/-0.3	4.5+0.4/-0.3	0.5	0.38
4.0*5.0	4.0+0.5/-0.4	5.0+0.5/-0.4	0.5	0.38
4.5*5.5	4.5+0.5/-0.4	5.5+0.5/-0.4	0.5	0.38
5.0*6.0	5.0+0.5/-0.4	6.0+0.5/-0.4	0.5	0.38
6.0*7.0	6.0+1.0/-0.5	7.0+1.0/-0.5	0.5	0.38
7.0*8.4	7.0+1.0/-0.5	8.4+1.0/-0.5	0.7	0.56
8.0*9.4	8.0+1.0/-0.5	9.4+1.0/-0.5	0.8	0.56
9.0*10.6	9.0+1.0/-0.5	10.6+1.0/-0.5	0.8	0.68
10*11.6	10.0+1.0/-0.5	11.6+1.0/-0.5	0.8	0.68
11.0*13.0	11.0+1.0/-0.5	13.0+1.0/-0.5	1	0.89
12.0*14.0	12.0+1.0/-0.5	14.0+1.0/-0.5	1	0.89
13.0*15.0	13.0+1.0/-0.5	15.0+1.0/-0.5	1	0.89
14.0*16.0	14.0+1.0/-0.5	16.0+1.0/-0.5	1	0.89
15.0*17.0	15.0+1.0/-0.5	17.0+1.0/-0.5	1	0.89
16.0*18.0	16.0+1.0/-0.5	18.0+1.0/-0.5	1	0.89
17.0*19.0	17.0+1.0/-0.6	19.0+1.0/-0.6	1	0.89
18.0*20.0	18.0+1.0/-0.6	20.0+1.0/-0.6	1	0.89
19.0*22.0	19.0+1.0/-0.6	22.0+1.0/-0.6	1.5	1.35
20.0*23.0	20.0+1.0/-0.6	23.0+1.0/-0.6	1.5	1.35
OEM is accepted, the size and color could as customer's request.
