Large capacity Agricultural irrigation pumps
Overview
Model QS Agricultural irrigation pumps are single-stage double-suction horizontal split centrifugal irrigation pump and used to transport irrigation water.
Application
The Agricultural irrigation pumps are widely used for farm or farmland, garden irrigation.
Advantage
20 years in Agricultural irrigation pumps producing pumps |
Construction
Performance
Performance Range
Flow rate:112~14400m3/h
Head:11~100m
Speed:500~2900rpm
Max Eff:92%
| Model | Flow rate | Head | Speed | Power | Eff | Iimpeller | Weight |
(QS) | (m3/h) | (m) | (rpm) | (KW) | (%) | (mm) | (kg) |
QS150 | 110~220 | 35~84 | 2900 | 30~55 | 67~80 | 186~250 | 145~150 |
QS200 | 160~351 | 31~100 | 2900 | 37~110 | 61~85 | 193~284 | 219~265 |
QS250 | 324~612 | 8.6~71 | 1450 | 22~132 | 72~86 | 224~460 | 405~565 |
QS300 | 504~972 | 8~98 | 1450 | 30~300 | 70~84 | 225~540 | 845~660 |
QS350 | 745~1663 | 10~140 | 1450 | 55~680 | 70~88 | 270~655 | 760~1580 |
QS400 | 900~1620 | 32~98 | 980~1480 | 155~500 | 71.5~84 | 510~535 | 1910 |
QS500 | 1150~2450 | 10.6~108 | 740~970 | 110~800 | 70~89 | 390~860 | 2000~4330 |
QS600 | 2304~4000 | 13~80 | 730~970 | 185~900 | 70~91 | 450~830 | 2500~4300 |
QS700 | 2111~4896 | 39.5~99.5 | 740~980 | 560~1250 | 52~92 | 415~850 | 5800 |
QS800 | 3960~7200 | 23.5~84 | 600~740 | 450~1600 | 77~92 | 715~990 | 5100~8300 |
QS1000 | 6000~9900 | 32~52 | 600~990 | 1250 | 79~87 | 670~695 | 10000 |
QS1200 | 5832~14400 | 6~95.7 | 500~745 | 710~3450 | 80~90 | 560~1200 | 12500~16000 |
Agricultural Irrigation pumps standard packing:
Outside: Standard fumigated wooden case
Inner: Stretch film
Bottom: Wooden pallet
1. Offer Agricultural irrigatio pumps solutions
2. Agricultural Irrigation pumps selection
3. Agricultural Irrigation pumps OEM available
4. Agricultural Irrigation pumps ODM available
5. Centrifugal Agricultural Irrigation pumps design
6. Centrifugal Agricultural irrigation pumps installation
7. Centrifugal Agricultural irrigation pumps maintenance
Shijiazhuang An Pump Machienry Co., Ltd is the base of slurry pump, slit pump, desulfurization pump and sewage pump. We have many technical and manage outstanding person who are high stuff and seasoned. Our company absorbs new science and technology fruit, empolder series of high level pump products. We can produce more than 500 kinds of pump products for the line of metallurgy, mine, electric power, coal, petrol and etc.
Especially Agricultural irrigation pumps, we already have 20 years experience in manufacturing.
How many countries had you exported the Agricultural irrigation pumps?
Australia, Russia, Finland, Mexico, Indonesia, India, Vietnam, Singapor, and America.
