singles stage double suction radial split case pump
Shijiazhuang An Pump Co., Ltd, the main pump products including slurry pump, desulfurization pump, gravel pump, sewage pump, impurity pump, split pump with large capacity, multistage pump with hjgh lift, centrifugal water pump and self priming pump, could meet various requirements of all the customers
1.PERFORMANCE:
Caliber |
DN80-800mm |
Capacity |
Q≤11600m³/h |
Head |
H≤200m |
Working pressure |
P≤2.5Pa |
Working temperature |
T≤105°C |
Working voltage |
U=380V,6KV,10KV |
2.General Description:
Type QS,QSH pumps are single stage, double suction with horizontally split casings.
Type QS ,QSH pumps are adoptable in factories, mines, water works, power stations, hydraulic engineering, irrigation or drainage services in agriculture, etc.
3.Structural Features:
A. Compact structure, space effective and much shorter axial dimensions.
B. Small vibration and low noise, achieved mainly by means of the follow:
1) The pump casing adopts the double-volute structure
2)The rotor part has short axial dimensions and a good rigidity.
3)The pump shaft adopts the imported high-precision bearing for the support.
4.Structural of spit case pump:
