Open Pit Mining Equipment Submersible Vertical Sump Slurry Bomba
Vertical Slurry Bomba Application
Applications about Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Chinese heavy duty vertical slurry bomba is mainly used for delivery the slurry which is strong corrosive with fine particles.
It is a kind of mining equipment.
This kind of sump bomba is widely used to transport slurry with strong corrosion and high concentration for many industries, such as metallurgy, mine, coal, electric power and so on, for example the cracking operations.
| Mining Dewatering Vertical Sump Slurry bomba in Laos The bomba work under the sump, but the motor installed in the ground. This is a open pit sand mining.
Model type: BP65 Flow rate: 81m3/h Head: 23m Speed: 1400rpm Efficiency:51% Shaft power: 9.7kw Motor power: 15kw Weight: 500kg Size: 1193x680x2950mm Inlet: 104mm Outle: 65mm |
Iron Mining Vertical Sump Slurry bomba In Austraila The bomba work for an iron mining. Our engineer also went to the working condition to helpl installation.
Model type: BP150 Flow rate: 421m3/h Head: 15m Speed: 7300rpm Efficiency:53% Shaft power: 31.4kw Motor power: 45kw Weight: 1850kg Size: 1870x1100x3986mm Outle: 150mm | |
Vertical Slurry bomba Overview
General Overview for Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Submersible mineral Submersible mineral vertical slurry bomba, vertical sump slurry bomba is cantilevered vertical slurry bomba with rubber liners, impeller and other wet end parts.
Heavy duty cantilevered vertical slurry bomba is designed for applications requiring vertical sump duties.
Fully elastomer lined or hard metal fitted.
The sump bomba do not have packing.
Optional recessed impeller and suction agitator available.
This is the vertical instructure vertical slurry bomba, but same thoery with the horizontal bomba.
Vertical Slurry bomba Performance Data
Performance Data sheet for Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
| Item | Data |
| Capacity(Flow rate) (Q) | 17~1267m3/h 4.7~352L/S |
| Head (H) | 4~40m |
| Speed | 350~2200rpm |
| Max Passed Particle Size | 65mm |
| Slurry Density | 60% |
| Slurry PH Rate: | 2~11 |
Vertical Slurry bomba Performance Curve Chart
Performance curve chart for Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Operating performance curve chart can help the end user know much about all of the models of Submersible mineral vertical slurry bomba vertical sump slurry bomba
Vertical Slurry bomba Materials
Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba wet end parts material list
Metal material | Rubber Material | ||
Item | Code | Item | Code |
Chrome alloy | Cr | Natural rubber | Ru |
Cast iron | - | Synthetic rubber
| Ternary ethylene, Nitrile rubber, Neoprene rubber, Butyl rubber |
Grey iron | HT | ||
Ductile cast iron | QT | ||
Stainless Steel | SS304, SS306, SS316L | ||
Duplex stainless steel | CD-4MCu | ||
Bronze | - | ||
Vertical Slurry bomba Construction
Construction of Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Vertical Slurry bomba Feature
Key points of Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Sump bomba do not need any Shaft seal and Shaft seal water,it is still workable without enough water.
About Company
Shijiazhuang An Pump Machinery is the top manufacturer of the bomba in China.
Our Histrody
Our Service
1. Offer Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba solution design as working condition,
2. Offer Installation & ajustment in working condition,
3. Accept OEM
4. Select centrifugal vertical slurry bomba & related equipement,
5. Sample available.
Slurry bomba services details:
Service | Specification |
1. Slurry bomba selection | Send us the vertical slurry bomba basic data (medium, head, flow rate...) |
2. OEM/ODM | Please show us the slurry bomba drawing |
3. Process design | Offer process design as slurry bomba working condition. |
Vertical Slurry bomba Packaging
Furmigated wooden case packaging for Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba
Shipping
Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba shipping can arrange by sea, air or express.
Our Questions
1. Other suggested products except Open Pit Mining Equipment Submersible Vertical Sump Slurry bomba?
| Sand gravel bomba | Horizontal slurry bomba | Submersible slurry bomba |
| | |
2. How to get your price about the vertical slurry bomba?
First, we must to make sure the model according your working condition, then the materials, shaft seal, painting and package specific need.
3. Is it avaliable to print our clients brand?
Totally accept as international rules.
4. How to connect you directly for the vertical slurry bomba solutions?
Leave message below.
Contact Us
For slurry bomba price list can contact our email below directly:
*~**~**~**~**~**~**~**~**~**~**~**~**~**~**~* *~**~**~**~**~* *~*
*~**~**~**~**~* *~**~**~**~**~**~**~**~**~**~**~**~* *~**~**~**~**~* *~*
Ailen
