Diesel Water Pump With 20L Fuel Tank
Shijiazhuang An Pump Machinery Co., Ltd
Shijiazhuang An Pump Machinery Co.,Ltd is mainly engaged in pump producing,
selling ,mechanical electronic and mining equipment trading business. We keep the "Quality equals to life, and integrity makes magnificent."
The main pump products include slurry pump,desulfurization pump,gravel pump,sewage pump,impurity pump,
split pump with large capacity,Multistage pump with high lift,centrifugal water pump and self priming pump,
could meet various requirements of all the customers.We have many technical and manage.
Diesel Water Pump With 12.5L Fuel Tank Specification
1. Outlet Diameter: 2''(50mm) to 12’’(300mm)
2. Flow Rates: 8m3/h~600m3/h
3. Head: 6m~63m
4. Horsepower: 1HP~125HP
5. Solid Passing: 20.63mm~76.2mm
6. Material: Cast iron, ductile iron, stainless steel, cast steel, aluminum, bronze
7. Diesel Driving: Water cooled or air cooled
8. Method of connection: Self priming pumps are available as basic units or may be flex-coupled, V-belt driven or engine mounted.
9. Drive Variation: Diesel engine , Electric Motor
10. Skid Mounted on Trailer: 2 wheels or 4 wheels trailer
11. Package: Exporting plywood case
12. Certification: ISO9001: 2000,CE
Diesel Water Pump With 12.5L Fuel Tank feature
QZX series self-priming pump belongs to self-priming centrifugal pumps. The key advantage is that this kind of pump
have stronger self-priming capacity. It do not need bottom valve on the pipe line, but the quantitative lead liquid must
be stayed before work.The pumps simplified the system of the pipes, and they improved the working condition
1) Stable performance, reliable operation
2) Rapid self-priming, high suction head
3) Back-pull-out construction: convenient for maintenance and troubleshooting.
Daily maintenance can be performed rapidly by common head tools, saving time and labor
4) Semi-open impeller structure and non-clogging design. Strong passing capacity,
diameter of maximum passing solid for P-12 is 76.2mm
5) Convenient usage: the pump can be mounted high and dry at floor level, with only
the suction line down in the liquid
Diesel Water Pump With 12.5L Fuel Tank Working Condition
Diesel Water Pump With 12.5L Fuel Tank Structure
Diesel Water Pump With 12.5L Fuel Tank Application
| Pump model | Application |
| self priming water pump |
1. environment protection, construction, fire protection, chemical industry, pharmacy, printing & dyestuff, brewage, electric power, electroplate, papermaking, washing for indsutry and mine, cool for device. 2. spray after setting up the rotating sprinkler on the farm or garden 3. suitable for clean water, sea water and cemical medium with acid and alkali and mushy slurry. 4. transport slurry to compressor anf filter with compressor and filter. |
| non blocking self priming sewage pump |
1. PH rate: 1~14 2. max particle size must not bigger than the 60% diameter of outlet. 3. delivery sewage water with big particle, long fiber, precipitate, wast ore and impurities, excrement, or some sewage works |
| self priming centrifugal oil pump |
1. suitable for petroleum industry, land terminal, oil tank 2. as marine cargo oil pump, bilge pump, fire pump, ballast pump, and for machinery cooling water circluation 3. delivery petroleum products(such as: gasoline, kerosene, diesel oil, and aviation fuel) sea water, clean water. |
