Marine Stainless Steel Sea Water Pump
Marine Stainless Steel Sea Water Pump Application
Industry |
Plumbing Applications |
General water supply |
Circulation of HVAC building systems , water booster service , boiler feed , general circulation service and more . |
Agriculture / Food / Beverage |
Irrigation , water supply , food processing , beverage processing , fertilizers . |
Manufacturing |
Pulp and paper fans , plastic & rubber , metal & steel , pharmaceutical , paper mills , air wash , marine ballast service . |
Fire / Disaster Relief |
Fire pumps , fire protection , flood control , disaster relief , federal / military . |
Utilities : Water / Wastewater |
Power Generation stations , dewatering , desalination , energy recovery turbines |
Chemical / Mining |
Chemical plants , refineries , petroleum distribution , coal sites , ethylene glycol pumping . |
Marine Stainless Steel Sea Water Pump Specification
Material:
1.Pump casing made of gray cast iron, ductile iron or cast steel. |
2.Impeller made of gray cast iron, silicon brass or stainless steel. |
3.Spindle in stainless steel or high carbon steel. |
4.Other materials can be used upon requirement. |
Feature:
1,Capacity: 5280~84000m3/h,
2,Head: 12~120m
3,Industrial pump
4,clean water pump
Technological Advantages
1. Bearing spacing between both ends is short, pump running stable, low vibration noise, and can increases the speed of running properly, to adapt to a wider range of performance.
2. Inlet and outlet at the same line, so that the pipeline layout is simple and convenient, beautiful.
3. The rotation of the same rotor can be reversed, reducing the risk of damage caused by the water hammer.
4. Unique design of high temperature, use of intermediate support, thick body, sealed cooling, bearing lubrication, so that the pump can run up to 200 ºC occasions, especially for heating network requirements.
5. Pump can be vertical or horizontal installed according to using conditions, seal can be mechanical seal or packing seal.
Marine Stainless Steel Sea Water Pump Parameter
Model |
Flow rate |
Head |
Speed |
Power |
Eff |
Iimpeller |
Weight |
(QS) |
(m3/h) |
(m) |
(rpm) |
(KW) |
(%) |
(mm) |
(kg) |
QS150 |
110~220 |
35~84 |
2900 |
30~55 |
67~80 |
186~250 |
145~150 |
QS200 |
160~351 |
31~100 |
2900 |
37~110 |
61~85 |
193~284 |
219~265 |
QS250 |
324~612 |
8.6~71 |
1450 |
22~132 |
72~86 |
224~460 |
405~565 |
QS300 |
504~972 |
8~98 |
1450 |
30~300 |
70~84 |
225~540 |
845~660 |
QS350 |
745~1663 |
10~140 |
1450 |
55~680 |
70~88 |
270~655 |
760~1580 |
QS400 |
900~1620 |
32~98 |
980~1480 |
155~500 |
71.5~84 |
510~535 |
1910 |
QS500 |
1150~2450 |
10.6~108 |
740~970 |
110~800 |
70~89 |
390~860 |
2000~4330 |
QS600 |
2304~4000 |
13~80 |
730~970 |
185~900 |
70~91 |
450~830 |
2500~4300 |
QS700 |
2111~4896 |
39.5~99.5 |
740~980 |
560~1250 |
52~92 |
415~850 |
5800 |
QS800 |
3960~7200 |
23.5~84 |
600~740 |
450~1600 |
77~92 |
715~990 |
5100~8300 |
QS1000 |
6000~9900 |
32~52 |
600~990 |
1250 |
79~87 |
670~695 |
10000 |
QS1200 |
5832~14400 |
6~95.7 |
500~745 |
710~3450 |
80~90 |
560~1200 |
12500~16000 |
Marine Stainless Steel Sea Water Pump Constructure
Marine Stainless Steel Sea Water Pump Picture
Marine Stainless Steel Sea Water Pump Packing and shipping
1. Offer Large capacity sea water pump solutions
2. Selection
3. OEM available
4. ODM available
5. Design
6. Installation
7. Maintenance
