Gold Mining Electric Mine Dewatering Pump Sand Dredging Pump
- Xingang
- T/T L/C D/P D/A Credit Card
You May Like
-
Battle Max Lime Mineral Processing Sand Dredging Pump
-
Top Quality High Efficiency Industrial Electrical Dewatering Sand Dredging Pump
-
Wear-resistant Material Gold Ash Mining Sand Dredging Pump
-
Heavy Duty Anti Wear Centrifugal for Mining Solid Slurries Sand Dredging Pump
-
CE Certification Power Station Flue Gas Desulphurization Sand Dredging Pump
-
Horizontal Abrasion Corrosion Resistant Diesel Engine in Suction Gold Dredging Ship Sand Dredging Pump
Product Details
Place of Origin | Hebei, China | Brand Name | AN PUMP | |
Model Number | AMG | Theory | Centrifugal Pump | |
Structure | Single-stage Pump | Usage | Other, coal washery, power plant, metallurgy, suction hopper, | |
Power | Electric | Standard or Nonstandard | Standard | |
Fuel | Other, motor or diesel or gasoline | Pressure | High Pressure | |
Application | Other, sand excavation, dredging, mining, |
Product Description
Cyclone Feed
Slag Granulation
Suction Hopper Dredging
Dredging
Barge Loading
Mill Discharge
Sand Reclamation
Sugar Beet
AMG/AMGH gravel pump , construction of this pump is of single casing connected by means of clamp bands and wide wet passage. The wet parts are made of Ni hard and high chromium abrasion resistance alloys.
The discharge direction of pump can be oriented in any direction of 360 degrees. This type of pump possesses the advantages of easy installation and operation, good performance of NPSH and abrasion resistance.
Drive types includes V-belts driven, flexible coupling driven, gear box driven, hydraulic coupler driven, variable frequency driven, thyristor speed control etc.
AMG/AMGH gravel pump are designed for continuously handling the most difficult higher abrasive slurries which contain too big solids to be pumped by a common pump. They are suitable for delivering slurries in mining, explosive sludge in metal melting, grudging in dredger and course of river, and other fields. Type AMGH pumps are of higher head ones
Model | Outlet Dia | Speed | Flow | Head | Max Power | Max Solid |
6/4AMG | 100 | 600-1400 | 36-250 | 7-56 | 60 | 82 |
8/6AMG | 150 | 800-1400 | 180-540 | 12-52 | 120 | 120 |
10/8AMG | 200 | 500-1000 | 180-820 | 12-56 | 560 | 178 |
12/10AMG | 250 | 400-850 | 360-1200 | 12-60 | 600 | 220 |
14/12G-AMG | 300 | 300-700 | 700-2700 | 8-70 | 600 | 241 |
14/12TU-AMG | 300 | 300-700 | 700-2700 | 8-70 | 1200 | 241 |
10/8F-AMGH | 200 | 500-1100 | 50-900 | 20-90 | 560 | 180 |
12/10G-AMGH | 250 | 350-700 | 500-2000 | 20-80 | 600 | 210 |
16/14TU-AMGH | 350 | 250-500 | 1000-2800 | 20-80 | 1200 | 230 |
Considering the importance of after sale services, An Pump Machinery offers a complete service as recommended spare parts list, maintenance catalogues, guarantee procedures, and other supports which customers need.
Regulations on the guarantee of pumps manufactured by An Pump Machinery
An Pump Machinery Company emphasizes on basic standards and quality development of manufactured pumps, so all the manufactured pumps are guaranteed to be longest service life since the purchase.
In order to facilitate the guarantee services for the pumps, An Pump Machinery will present the product’s identification containing the stamped guarantee card, together with regulations for the guarantee.
To be aware of the conditions which cover the guarantee for the pumps, please refer to guarantee conditions page in the product’s identification.
Manual to Install and Maintain
In order to support the products, An Pump Machinery has prepared the manual for installation and maintenance of different types of pumps.
Customers are recommended to study the manual carefully and consider all the points when installing, using and maintaining, in order to maximize the efficiency and the life of pumps.To see the content of the manuals, click on the respective group.
Pump Spare Parts
Standard spare parts of An Pump Machinery have been supplied in order to support the products with high quality parts.
To see the technical number for pump parts, and the constituents of every category of pumps, plus the necessary spare parts for each pump.
