high-performance gasoline engine gold dredging pump machine
General information of suction sand pump dredging ship
AMG/AMGH centrifugal dredge Pump, Construction of this pump is of single casing connected by means of clamp bands and wide wet passage. The wet parts are made of Ni hard and high chromium abrasion resistance alloys.
The discharge direction of pump can be oriented in any direction of 360 degrees. This centrifugal dredge Pump possesses the advantages of easy installation and operation, good performance of NPSH and abrasion resistance.
Introduction-- gasoline engine dredging pump
1) The gravel pumps are designed for continuously handling the most difficult higher abrasive slurries which contain too big solids to be pumped by a common pump. They are suitable for delivering slurries in Mining, Explosive sludge in metal melting, Dredging in dredger and course of rivers, and other fields. Type SHG pumps are of high-head ones.
2) Construction of this pump is of single casing connected by means of clamp bands and wide wet-passage. The wet -parts are made of Ni-hard and high chromium abrasion-resistance alloys. The discharge direction of pump can be oriented in any direction of 360 degree.
3) This type of pump possesses the advantages of easy installation and operation, good performance of NPSH and abrasion resistance.
Technical parameters of gasoline engine dredging pump
Model |
Outlet Dia (mm) |
Speed (rpm) |
Flow (m3/h) |
Head (m) |
Max Power (kw) |
Max Solid (mm) |
6/4D-AMG |
100 |
600-1400 |
36-250 |
7-56 |
60 |
82 |
8/6E-AMG |
150 |
800-1400 |
180-540 |
12-52 |
120 |
120 |
10/8F-AMG |
200 |
500-1000 |
180-820 |
12-56 |
560 |
178 |
12/10G-AMG |
250 |
400-850 |
360-1200 |
12-60 |
600 |
220 |
14/12G-AMG |
300 |
300-700 |
700-2700 |
8-70 |
600 |
241 |
14/12TU-AMG |
300 |
300-700 |
700-2700 |
8-70 |
1200 |
241 |
10/8F-AMGH |
200 |
500-1100 |
50-900 |
20-90 |
560 |
180 |
12/10G-AMGH |
250 |
350-700 |
500-2000 |
20-80 |
600 |
210 |
16/14TU-AMGH |
350 |
250-500 |
1000-2800 |
20-80 |
1200 |
230 |
gasoline engine dredging pump performance curve
