paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

AJY high efficient energy saving pulp pump, with advantages from broad and domestic, we take advantages design theory to develop new type pump, hydraulic design with theory “relative suction, relative obstruction”, The pump wet parts hydraulic performance is compliance with pump flow law. Then reduce the erosion and wear of wet parts liquid. Greatly improve the pump efficiency and service life.

Main features-paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

1.Totally open wide flow impeller makes pump no-blocking and transporting thicker slurry. Axial force is low, and complete pump has no vibration. The weight of impeller is lighter than closed or semi-open impeller. When starting the pump, the radial shear stress of shaft is lower, which makes each part long service life and low repair rate.

2. Use coupling. Under the circumstance of not disassembling the pump’s import and export, impeller, back wear-resisting plate and bearing bracket can be disassembled and assembled.

3. Totally open wide flow impeller makes pump no-blocking and transporting thicker slurry. Axial force is low, and complete pump has no vibration. The weight of impeller is lighter than closed or semi-open impeller. When starting the pump, the radial shear stress of shaft is lower, which makes each part long service life and low repair rate.

4. Use coupling. Under the circumstance of not disassembling the pump’s import and export, impeller, back wear-resisting plate and bearing bracket can be disassembled and assembled.

Seal: mechanical seal and packing seal

Advantages-paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

1. High efficiency, Energy saving,operation efficiency is 3-10% higher than ordinary pulp pump. Energy saving to 15-30%

2.Good NPSH, long service, actual using life is twice-third than ordinary pulp pump

3.High concentrations,Non-clogging transfer pulp concentration max to 6%

4. Reasonable structure, easy maintenance: pump head is front, rear casing structure, when maintenance there is no need to remove pipe line, only remove the electric motor backwards.

Then could disassemble and repair the pump.

Application- paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

1 Paper industry

Used for transporting pulp with the concentration below 6%.

The cycle of transmission media, promotions and pressure that is used in alkali recovery process

2 Sugar industries

Delivering syrup for concentration below 4%, viscosity below 150mm2 / s

3 Urban sewage industries

It is widely used in sewage treatment process for the cycle of transmission media, upgrading and pressure.

Performance chart-paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

Structure-paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

Materials-paper making non leakage with Two Kinds of Impellers Low Price syrup pump pulp pump paper slurry pump

1. pump casing: cast iron, duplex stainless steel

2. impeller: duplex stainless steel

3. front and back wear-resisting plate: duplex stainless steel

4. pump cover: cast iron, duplex stainless steel

5. shaft: 2Cr13
