Diesel End suction Centrifugal Water Pumps
QI(R) Centrifugal end suction pump is a single stage, single suction pump for pumping clean water and the other liquids physically and chemically similar to the clean water.
This pump is suitable for public water supply and drainage duties in industries and land irrigation also in agriculture as the diesel engine agriculture irrigation water pump
We use the world first level diesel engine and the latest techincal at fuel feed and environmental protection to make our OI(R) Farm Agricultural irrigation diesel engine water pump for field irrigation pump set to be your best choice at irrigation pumps!
Diesle Engine of the QI farm irrigation diesel water pump
|
We use the world first level diesel engine manufacturer's diesel engine for our irrigation pump set. We could also supply the Spare parts both our pump and the diesel engine pump we supplied and you could also get the afet sales service from all ove the world! |
Material of Diesel End suction Centrifugal Water Pumps
Material |
Common(G) |
Wear resistant(P) |
Ultrawear resistant(N) |
Stainless steel(F) |
Pump casing |
HT200 |
QT500-7 |
Wear resistant |
SS304 |
Pump cover |
HT200 |
QT500-7 |
Wear resistant |
SS304 |
Impeller |
SS304 |
Duplex SS |
Duplex SS |
Duplex SS |
Liner of front and behind |
Wear resistant steel |
Wear resistant steel |
Wear resistant |
Duplex SS |
Bearing body |
HT250 |
HT250 |
HT250 |
HT250 |
Shaft |
3Cr13 |
3Cr13 |
3Cr13 |
3Cr13 |
Shaft sleeve |
2Cr13 |
2Cr13 |
2Cr13 |
SS304 |
Diesel End suction Centrifugal Water Pumps features
1.Capacity 6.3-400m3/h
2.Head 5-125m
3.Speed 2900 r/min or1450 r/min
4.Discharge 50-200mm
5.Medium temparature: No more than102 degree centigrade
6.Working pressure: No more than0.6 centrifugal pump
7.Diesel engine type: Water cooled or air cooled
8.Diesel engine power: 10HP-2000HP
9.Diesel engine started: Electric
Type |
Flow (m3/h) |
Head (m) |
Power (KW) |
QI50 |
3.4-15 |
3.7-68.8 |
0.55-11 |
QI65 |
6.8-30 |
3.7-126.8 |
0.55-30 |
QI80 |
13.6-60 |
3.6-128 |
0.55-45 |
QI100 |
27.3-120 |
3.4-115.5 |
1.5-75 |
QI125 |
56-240 |
8.5-132.5 |
2.2-110 |
QI150 |
99-240 |
12.4-57.5 |
15-55 |
QI200 |
197.7-460 |
14.8-55.8 |
30-90 |
General description of Diesel End suction Centrifugal Water Pumps
The centrifugal pump is single-stage and single-suction centrifugal pump, which designed according to ISO2858 international standard and the replacement product of BA-type water pump. It is widely used in industrial and municipal water supply and drainage, agricultural irrigation and can also be used for conveying water or physical and chemical properties similar to water or other liquids bellow 80° C.
The pump is also designed according to ISO2858 international standard, which designed for boiler feed water and hot water circulation system. It could also be used for industrial and municipal water supply and irrigation, but the temperature should be not higher than 150° C.
Performance chart of Diesel End suction Centrifugal Water Pumps
Standard wooden case packing of Diesel End suction Centrifugal Water Pumps
