1000m3/hr irrigation diesel water pump chinese water pump

Name: 1000m3/hr irrigation diesel water pump chinese water pump
Brand: An Pump
Availability: InStock

FOB Price

USD $600 - $7,900 / Set

1 Set(Min.Order)

Supply Ability 400 Set / Sets per Month
Port Tianjin/Shanghai/Guangzhou/Shenzhen
Payment TermsT/T L/C Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	An Pump
Model Number	QS agricultural irrigation water pump	Theory	Centrifugal Pump
Structure	Single-stage Pump	Usage	Other, irrigation pump,split case pump,double suction pump
Power	Other, electric or diesel	Standard or Nonstandard	Other, standard,irrigation pump,split case pump,double suction pump
Fuel	Other, electric water pump/diesel water pump	Pressure	Other, high pressure pump,stainless steel pump
Application	Other, agriculture/irrigation/industrial/, water, sea water, hot water, cooling water, rain,sewage etc

Product Description

1000m3/hr irrigation diesel water pump chinese water pump

Product Description

1000m3/hr irrigation diesel water pump chinese water pump -- large water pumps

Type QS pumps are single stage, double suction with horizontally split casings.They are suitable for pumping clean water or liquid similar to it in physical and chemical properties at a temperature not exceedding 80 °C ( for common material ) .

The main components of QS,QSH pump are listed as follows:lower half casing , upper half casing , impeller , shaft , double suction sealing , shaft sleeve , bearing housings , and couplings .

1000m3/hr irrigation diesel water pump chinese water pump features

1. Large flow rate

2. Operation stability

3. Double-volute structure

4. Resonable price

5. OEM available

1000m3/hr irrigation diesel water pump chinese water pump performance parameters

Type	Flow(m3/h)	Head(m)	Speed(rpm)	Power(KW)
QS150	112--220	35--84	2900	30--55
QS200	160--351	31--100	2900	37--110
QS250	324--612	8.6--65.1	1450	22--132
QS300	504--1663	8.7--140	1450--1470	22--680
QS350	745--1570	10--125	1450--1470	55--630
QS400	900--1620	32--85.5	980--1480	440--500
QS500	1150--3800	10.6--108	740--970	110--800
QS600	2300--4000	13--80	730--970	145--730
QS700	2111--4896	39.5--99.5	742--980	397--1252
QS800	3960--6878	23--84	600--750	450--1600
QS1000	6600--9900	32--52	600	1250
QS1200	5832--14400	6--95.7	500--745	710--3450

1000m3/hr irrigation diesel water pump chinese water pump curve

1000m3/hr irrigation diesel water pump chinese water pump constructure

Pump pictures

Pump Application:

1000m3/hr irrigation diesel water pump chinese water pump on site application

Industry	Plumbing Applications
General water supply	Circulation of HVAC building systems , water booster service , boiler feed , general circulation service and more .
Agriculture / Food / Beverage	Irrigation , water supply , food processing , beverage processing , fertilizers .
Manufacturing	Pulp and paper fans , plastic & rubber , metal & steel , pharmaceutical , paper mills , air wash , marine ballast service .
Fire / Disaster Relief	Fire pumps , fire protection , flood control , disaster relief , federal / military .
Utilities : Water / Wastewater	Power Generation stations , dewatering , desalination , energy recovery turbines
Chemical / Mining	Chemical plants , refineries , petroleum distribution , coal sites , ethylene glycol pumping .

Packaging & Shipping

1000m3/hr irrigation diesel water pump chinese water pump packing and shipping

Our Services

1. Offer Large capacity pump solutions
2. Selection
3. OEM available
4. ODM available
5. Design
6. Installation
7. Maintenance
