Home > Products > Irrigation Pump > Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Agricultural Deep Well 250mm Submersible Irrigation Water Pump
- 300 Set / Sets per Month
- Tianjin/Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Hebei, China | Brand Name: | AN PUMP | Model Number: | ASJ Agricultural Submersible Stainless Steel Irrigation Water Pump |
Theory: | Other, stainless steel centrifugal pump | Structure: | Other, Multistage submersible water pump | Usage: | Other, submersible water pump |
Power: | Other, Electric submersible pump, electric submersible pump | Standard or Nonstandard: | Nonstandard | Fuel: | Other, Diesel stainless steel pump |
Pressure: | Other, High pressure water submersible pump | Application: | Other, submersible irrigation pump, Agricultural irrigation deep well pump |
Product Description
Agricultural Submersible Stainless Steel Irrigation Water Pump
Overview for Agricultural Deep Well 250mm Submersible Irrigation Water Pump
1.Filled water into motor cavity, tighten and pouring water, vent plug, otherwise it can’t be used.
2.In the electric condition, on land, the Commissioning time(pilot running) time can’t be more than 1 seconds.
3.The electric submersible pump can’t be used when lying or tilt.
4.The pump must be completely submerged into water, but the submerged depth no more than 70 m
5. Wire and cable connection should be operated as rules (the following)
Application for Agricultural Deep Well 250mm Submersible Irrigation Water Pump
1. Deliver deep well water
2. Irrigation for farm, garden
3. Drink for life
4. Wast water dewatering
Or other water delivery from deep well.
Construction for Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Material of Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Impeller: Cast iron HT200,or stainless steel
Pump bowl: Cast iron HT200,or stainless steel,such as ss304 ss3016
Pump shaft: Cold-drawn steel with chrome plating,or stainless steel ss304 ss316
Motor Seal: Rubber O-ring seal,mechanical seal
Feature of Agricultural Deep Well 250mm Submersible Irrigation Water Pump
100% Copper wire with overload protector
Cold-rolled silicon steel sheet, with high-speed punching, improve the efficiency and precision.
CNC precision automatic lathe for smoother shaft
Anti-rust treatment castings and electrophoresis
Automatic machine for spool wire and roll machine for tie wires
Working conditions about Agricultural Deep Well 250mm Submersible Irrigation Water Pump
1. Water temperature ---- ASJ model:≤20°C,ASJR model: ≤90 °C
2. Sediment concentration in water can not exceed 0.01%.
3. 380V voltage or as request deviation is no more than ±5%, frequency is 50HZ or 60hz, three -phase power deviation is no more than ±1%.( adjusted per customer's detailed demand)
4. Motor cavity must be filled with water.
5. The first stage impeller of the pump should be more than 2mm below the moving water surface, pump unit should be less than 70m below the static water level.
6. The distance from the motor bottom to the bottom of the well must be more than 3m.
Performance about Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Model | Capacity (m3/h) | Head (m) | Motor (kw) | Outlet dia (mm) |
100 | 2-10 | 40-2281 | 0.37-7.5 | 1.5 |
150 | 6-32 | 26-300 | 3-18.5 | 2 |
175 | 10-50 | 26-247 | 3-25 | 2 |
200 | 20-80 | 40-450 | 4-45 | 3 |
250 | 32-160 | 20-480 | 5.5-110 | 4-5 |
300 | 200-320 | 15-160 | 18.5-140 | 5-6 |
350 | 250-500 | 20-100 | 30-140 | 6-8 |
Packaging about Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Shipping about Agricultural Deep Well 250mm Submersible Irrigation Water Pump
Offer irrigation solutions: like the garden irrigation deep well pump. Or other farm irrigation pump
AN PUMP Brief Introduction:
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An Pump Machinery company has our own type selection & design, research and development team, Assure to provide our efficient energy-saving design, use and maintenance solutions for the slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps.
Main Products:
An Pump Machinery manufactured slurry pumps, sewage pump, water pump, chemical pumps, Agricultural Garden Farm Irrigation 2 Inch Electric Deep Well Submersible Water Pump, fire pumps, irrigation pumps and other products are exported to over 90 countries around the world. The application covers many fields, such as dressing ship, tailings transportation, mining pumps, steel & power desulphurization, boiler feed water, construction, irrigation, water conservancy facilities, sewage treatment.
Engineer Department:
Experienced technical personnel is the powerful guarantee for quality products of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps. An Pump Machinery technical team set up five R & D teams: hydraulic engineering, water pump structure, new materials research and development, casting, molding etc. Except the commonly used CAD and other design software, the technical teams also use CAPP computer-aided industrial design and CFD hydraulic design software. They combine years of experience in the practical application of the products, repeated use of water conservancy GIS, MIS software and simulation analysis system software demonstrated, calculations, the theoretical calculations product of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps are accurate and consistent with the actual performance. It allowing users to meet the needs while significantly reducing the investment costs, improves An Pump Machinery Company's strong core competitiveness.
An Pump Machinery Company’s slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps and other production line are well-equipped, such as casting furnaces, vertical lathe, cutting tools, boring and milling machining centers production line equipment are fully automatic data control; Precision casting molds and resin-bonded sand, precoated sand casting process, is a powerful pump parts guarantee of quality and appearance; Automatic curve heat treatment furnaces control pump accessories heat treatment process automatically and appropriately; International advanced pump detection equipment for signal acquisition, digital filtering and calibration ensure the accuracy of the data; Spectrograph, liquid analyzers and other testing equipment ensure the reliability and stability of the material; These advanced manufacturing and testing equipment ensure the quality and stability of slurry pump, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps and other products.
AN PUMP Development:
For the research and development of new materials for slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps, An Pump Machinery’s engineers constantly strive to explore casting and set up a new materials R&D team. The products meet API610 standards, in addition to Cr27, high-chromium alloy, SS304, SS316, SS904, CD-4MCu, duplex stainless steel and other wear & corrosion resistant alloys, R-type rubber corrosion resistant heavy flow components, corrosion-resistant high-strength teflon material, high-crystalline silicon ceramic corrosion-resistant materials were gradually developed. This reached advanced level in domestic and international.
In the era of rapid development of science and technology, An Pump Machinery team takes the entrepreneurial spirit "excellence and constant product quality, brand known worldwide", business purpose "the achievements of create brand enterprise and industry pioneer", to help you out and provide quality & cheap innovative products, with corporate philosophy of Kinda technical specialists and sophisticated equipment as backup, and work together with you to create brilliant!
