Accurately Measured Hot Metal Detector

Specifications

1.Professional in detecting gold
2.Accurately measured the temperature of an object
3.High anti interference of ambient light

Product Overview

The Hot metal detector can meet the plate crossed automatic rolling process and precise measurement of shear crossed requirements

Product Features

Using semiconductor laser as light source, the marking instrument with a light output power, marking the resolution is good, more than 10,000 hours service life, the whole machine is small (or according to the site request) and so on. When used in the field, especially for bilateral and unilateral hot plate shear play a key role.

Technical Parameter

Model number Item	ZYT-HX-3	ZYT-HX-4
Rated supply voltage	AC220V	AC220V
Power	≤10 W	≤5 W
Output power laser tube	350 mW	150 mW
Light source	Semiconductor laser	Semiconductor laser
Wavelength	532 nm of green light	650 nm red light
Line length	30 m (adjustable)	20 m (adjustable)
Line width	2-10 mm (adjustable)	2-10 mm (adjustable)
Work  environment temperature	-15 C  90 C  (45 C  add water cooling or air cooling )
Work time	24 hours of continuous work, 10000 hours
