Automatic Laser Leveling Distance Instrument
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
AIGER
Model Number:
ZYT-0040
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin&Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Laser Distance Measuring InstrumentNegotiableMOQ: 1 Set -
Laser Distance Measure MeterNegotiableMOQ: 1 Set
-
High-temperature Sensor for DistanceNegotiableMOQ: 1 Set
-
Accurately Measured Hot Metal DetectorNegotiableMOQ: 1 Set
-
Wholesales Popular Laser Security Beam SensorNegotiableMOQ: 1 Set
Place of Origin
Beijing, China
Brand Name
AIGER
Model Number
ZYT-0040
Size
195 * 55 * 115mm
Precision
± 1mm
Specifications
1.Measurement accuracy:1mm2.Patented special design
3.Competitive price laser level
4.Excellent quality and service
Product overview
The Automatic laser leveling instrument which uses laser to measure the phase comparison method, can be measured without contacting with the surface or the reflective target surface.
The product structure design is reasonable, with adjustable mounting bracket, purge the lens unit, and air cooling device. It is suitable for industrial applications, especially for high-precision, and non-direct contact applications, such as crane operation locate and metallurgical production line control and so on.
Product features
- Mm level measurement accuracy
- Continuous detection of a moving object
- For high temperature/dusty environment
- Precision-heavy-no need to reflect board
- With regional test ,control system and numeration function
Product type
ZYT-0040-1 10Hz RS232/RS422
ZYT-0040-2 50Hz RS232/RS422
ZYT-0040-3 ProfiBus
ZYT-0040-4 Ethernet Network
ZYT-0040-7 CANopen
Technical target
- Accuracy: ± 1mm
- Resolution rate: 0.1mm
- Repeatability: 0.5mm
- Measuring distance: 0.1 ~ 30m of any surface
30 ~ 150m need to add reflectors - Supply voltage: 10 ~ 24VDC
- Power consumption: 1W
- Laser Level: 650nm visible red
- 2 levels of security laser≤ 1mW
- Switch capacity: alarm output
- Simulation volume: 4 ~ 20Ma
- Protection class: IP65
- Dimensions: 195 × 55 × 115mm
- Housing: Aluminum
- Life: more than 50,000 h
- Weight: 2.5kg
Shape figure
