Help CenterHigh Temperature Laser Distance Measure Device
Related Products
Specifications
1.High accurate measuring tool2.High measurenent precision
3.The phase comparison method
4.Great service,reasonable price
Product overview
The ZYT-0050-1 / 2 series High temperature laser distance measure device have IP66 heavy industry protection grade ,and the optional protective, dust, air cooling, water cooling and quickly change device of window,which can ensurethe instrument be used safely and effectively in high temperature, dust and other harsh industrial environment .
The ZYT-0050-1 / 2 series laser range finder with a spring cushion three point mounting bracket, installation simple solid. The mounting bracket base has a horizontal and a vertical two kinds of installation.
Product features
1.2level laser grade
2.Near distance measurement without reflector
3.up to millimeter level measurement accuracy
vides a variety of interfaces such as: RS232 / 422,4-20mA current, ProfiBus, E-net
5. IP 66level of protection, high protection level
6.low power consumption
lid structure compact
8.a wide range of applications
Product type
ZYT-0050-2 50Hz RS232/RS422
Working principle
The industrial laser ranging sensors usesthe phase comparison principle for measurement. Laser sensor transmits different frequency visible laser beam from the object to be measured, receiving back scattering laser, and then compare the received laser signal to a reference signal,finally by the microprocessor calculates the corresponding phase shift the distance corresponding to between objects. The measurement precision can reach mm level.
Performance index
| Measuring distance | 0.1-30,natural object safce,up to 150m |
Working temperature |
-20°C-70°C |
| Measuring precision | ±2mm | Storage temperature | -20°C-70°C |
| Resolution | 0.1mm | Supply voltage | 10V-30V |
| Repeatability | 1mm | Measurement of frequency | 10Hz/50Hz |
| Laser divergence angle | 0.6mrad | Weight | 2Kg |
| Laser level | 2 | Data interface | RS232/RS422 |
| Protection grade | IP65,Aluminum shell | Analog output | 4-20mA |
Application illustration
