Environment Friendly Greenhouse Solar Powered Attic Ventilation Fan

Product Description:

Solar Thermostatic Ventilator / Solar Attic Fan

• The solar thermostatic ventilator is common used in all types of greenhouses and other small space.
• The solar fan needs to be assembled at the place where have enough sun. It is suitable for small space around 5-7 m³ or several sets can be used together to have a better ventilation and air exhaust.
• It will convert solar energy into electrical energy to lead a fan twirl to meet the demand of small space’s automatic ventilation, air exhaust and cooling through setting up a working temperature by thermostat switch, temperature range 0-50 degrees.
• The solar fan including a solar photovoltaic cell panel, thermostat switch, directly current fan, aluminium shell.

Product Characteristic:

•  Fully solar thermostatic control ventilation.
•  Keeping air circulation.
•  Cooling indoor temperature
•  Give your plants optimum conditions
•  No batteries or electricity required, save utility bill
•  High reliability, minimum maintenance, long uselife, easy assembly, automatic operation

Specification:

Solar Fan / Thermostatic fan

Item No.: HX-F8
Mounting: Roof fan
Voltage/Power: 12V/8W; 12V/15W
Air Volume: 94CFM
Venting: 2.60CBM/min
Materials: Aluminium, galvanized steel, plastic
Product size: 300*300*7mm
Weight: 2.5kg

Assembly:

1. Choose a place Keep the solar photovoltaic cell panel perpendicular to sunlight to receive the best light, avoid lightproof object cover the cell panel
2. Make a installation holes or fixing support for the fan at the suitable place, cut a square hole, the size according to overall size of the ventiltor shell, for the ventilator sitting in and the fan intake need to face inside of the room. Fix the ventilator on the wall or support and then put silicone at each contact surface.

 Other greenhouse accessories from us:

Automatic roof vent / side louver opener

Greenhouse Louver:

Plant hanger clip:

made of plastic and can used in all type of aluminium greenhouses

Greenhouse staging/shelving:

many other types and sizes available
