SVC type AC Automatic Voltage Regulator(stabilizer)
SVC500VA, 1000VA, 1500VA, 2000VA, 3000VA, 5000VA, 10KVA
15KVA,20KVA,30KVA,45KVA,60KVA
1.General:
When the voltage fluctuates or the load varies, automatic sampling control circuit
will send a signal to drive the servo motor which can adjust the position of carbon
brush, then the output voltage will be adjusted to rated value and get a steadystate.
2.Parameters:
Input voltage: 150-250V (1P)
Output voltage: 220V and 110V
Stabilization accuracy: 220V±3% and 110V±6%
Frequency: 50Hz/60Hz
Debug time: ≤1s (with the input voltage variation of 10%)
Overload power factor: 0.8
Efficiency: ≥90%
Dielectric strength: 1,500V/min
over voltage: 246±4VAmbient t
emperature: -10±40°CRelative
humidity: ≤95%
Temperature rise: lower than 60°
CWave form distortion: no additional wave form distortionInsulation
resistance: ≥2MΩ
