CE STANDARD FIBERGLASS PPR PIPE PRODUCTION LINE
- 50 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Application: | Pipe | Plastic Processed: | PP |
Screw Design: | Single-screw | Automatic Grade: | Automatic | Place of Origin: | Shanghai, China |
Brand Name: | CISSCO | Model Number: | CS-PPR | Voltage: | 380V |
Power(W): | 120kw | Dimension(L*W*H): | 26m*3m*3m | Weight: | 20 tons |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
FIBERGLASS PPR PIPE LINE1. Big capacity: 200-600kg/hr;
2. One, two, four pipes one time;
3. Good quality: CE standard.
FIBERGLASS PPR PIPE PRDUCTION LINE
1. General information of fiberglass ppr pipe production line:
Raw material & formulation | PP resin, All the material should be mixed completely. | |
Melt capacity | 350-400kg/h (depending upon pipe dimension and reference material) |
|
Production Efficiency | 4kg/Kw, Very high working efficiency Other Chinese extruders: 3kg/Kw |
|
Central height | 1000mm |
|
Quantity of color stripe | 1line 2lines 4 lines |
|
Max. extrusion speed | Max: HDPE ≥25m/min PP-R≥15m/min |
|
Operation direction | From right to left (face to the operation panel) |
|
Machine color | Standard color: RAL7016 (Anthracite grey); |
|
Final product |
|
|
2. Pipe species and size list of fiberglass ppr pipe production line:
No. | O.D. (mm) | Wall thickness (mm) 1 | Wall thickness (mm) 2 |
1 | 16 | SDR17 | SDR11 |
2 | 20 | SDR17 | SDR11 |
3 | 25 | SDR17 | SDR11 |
4 | 32 | SDR17 | SDR11 |
5 | 40 | SDR17 | SDR11 |
6 | 50 | SDR17 | SDR11 |
7 | 63 | SDR17 | SDR11 |
3. Machine list of fiberglass ppr pipe production line:
No. | Name | Qty. |
1 | Vacuum loader 400kg/h | 1set |
2 | Hopper dryer 400kg/h | 1set |
3 | BRD60/38 Single Screw Extruder With PLC Controller | 1set |
4 | SJ25/25 Color Stripe Co-extruder | 1set |
5 | Die head | 1set |
6 | Disk vacuum calibrator | 7sets |
7 | BR-VT/63/2/9 Two Chambers Vacuum Calibration Tank | 1set |
8 | BR-SB/63/9 Spray Cooling Tank | 1set |
9 | BR-HC/63 Two-belt Haul-off | 1set |
10 | BR-CF/63 Guillotine Cutter | 1set |
11 | Double Station Winder 16-63mm | 1set |
4. Pictures of fiberglass ppr pipe production line :
5. Contact me for fiberglass ppr pipe production line:
5.1. Skype: louies.cissco
5.3. Address: Shanghai, China
5.4 Cell: 0086 18917527205
