POLYCARBONATE CORRUGATED WAVE ROOFING SHEET MACHINE
Benefits of PC profiles – Big Market
PC panels are an extremely flexible instrument with applications in the field of architecture and in the building industry. Light, easy to work, ductile in shapes and colours, all this makes hollow profiles in PC and PMMA - HIPMMA an unequalled and extraordinary material. Many applications produced with our lines were installed more than twenty years ago.
I. Equipment Main Technology Parameter of POLYCARBONATE CORRUGATED WAVE ROOFING SHEET MACHINE
1. Use material: Virgin or recycled PC pellet/ flakes
2. Product width: 800-2200mm
3. Product thickness: δ=0.5-10.0mm
4. Max. output: 200-500kg/h
5. Voltage condition: 350V-420V/3 Phase/50Hz
6. Sheet structure: A+B+A, three layers co-extrusion
7. Production speed: 6m/min
8. Installed power: 300KW
II. Machine scope of POLYCARBONATE CORRUGATED WAVE ROOFING SHEET MACHINE :
Code | Name | Unit | Quantity | Remark |
1 | Main single screw extruder | set | 1 | for PC |
2 | Co-extrusion single screw extruder | set | 1 | for UV |
3 | Screen changer | set | 1 |
|
4 | Gear pump | set | 2 |
|
5 | Die head | set | 2 |
|
6 | Extrusion distributer | set | 1 |
|
7 | Double-roller haul-off unit | set | 1 |
|
8 | Roller temperature controller | set | 1 |
|
9 | Vacuum calibrating unit | set | 1 |
|
10 | Cooling conveying bridge | set | 1 |
|
11 | Edge cutting unit | set | 1 |
|
12 | Rubber roller haul-off unit | set | 1 |
|
13 | Cross cutting unit | set | 1 |
|
14 | Electrical control cabinet | set | 1 |
|
III. Pictures of POLYCARBONATE CORRUGATED WAVE ROOFING SHEET MACHINE
Loyal Luo, Sales Export & Business Developer
CissCo Machinery Co., Ltd.
Mob.: +86 18817937157 I Office: +86 2138726398 / 99
Email: market02@ I Skype: cisscomachine03 I Web:
Add.: 30B, No.58 New Jinqiao Road, Pudong, Shanghai, China
About Us: CISSCO MACHINERY CO., LTD
Cissco Machinery Co., has been engineering and manufacturing a series of EXTRUSION MACHINERY for more than 10 years and has thus acquired an extensive expertise in the supply of manufacturing machinery; having based ourselves on the features demanded by large companies in more than 30 countries.
Our Service
• We design, engineer and manufacture and customized the extrusion line.
• Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
• Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our clients factory
• Support: We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
