PP PE FLAT YARN MAKING MACHINE AND STRETCH LINE,RECYCLED PP PE FLAT MONOFILAMENT EXTRUSION LINE.flat Yarn Making Machine
US$ 100,000 - 500,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Application:
Wire
Plastic Processed:
Other, PP/PE/PET pellet or flakes
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PLASTIC MONOFILAMENT YARN EXTRUDER MACHINE,monofilament Yarn MachineUS$ 1 - 200,000MOQ: 1 Set -
CE STANDARD PP PET MONOFILAMENT YARN MAKING MACHINERYUS$ 100,000 - 500,000MOQ: 1 Set
-
Plastic Filament Extruding Machine,pet Monofilament Yarn Extruding LineUS$ 100,000 - 500,000MOQ: 1 Set
-
PLASTIC MONOFILAMENT YARN EXTURDER MACHINE,polypropylene Yarn MachineUS$ 100,000 - 500,000MOQ: 1 Set
-
PP Monofilament Yarn Extruder Machine For BrushUS$ 100,000 - 120,000MOQ: 1 Set
Application
Wire
Plastic Processed
Other, PP/PE/PET pellet or flakes
Screw Design
Single-screw
Automatic Grade
automatic
Place of Origin
Jiangsu, China
Brand Name
CS
Model Number
JYPL
Voltage
380V/50HZ or at optoinal
Power(W)
TBC
Dimension(L*W*H)
30m
Weight
25-35T
Certification
ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
PLASTIC MONOFILAMENT YARN EXTURDER MACHINE
PP PE FLAT FILM YARN MAKING MACHINE AND STRETCH LINE
PP PE FLAT FILM YARN EXTRUDER MACHINE
Advantage for pp/pe flat monofilament yarn making and stretch machine
This line is designed and manufactured on the basis of world advanced technology and long-term experience.With super-high capacity,high quanlity,high efficiency,low consumption,it can reach the minimum personnel cost and site area.Especially in producing PP/PE special yarn,such as PE tarpulin,warp yarn for jumbo bag etc,this line has more competition power. The capacity of this line is double than other normal tape line.
Main technical parameter:
| Item | SJPL -500 | SJPL-650 |
| Max extrusion volume | 500kg/h | 650kg/h |
| Screw Diameter | 100mm | 110mm |
| Ratio of L/D | 33:1 | 33:1 |
| Rotation speed of screw | 20-120r/min | 20-120r/min |
| Length of mold lip | 1100mm | 1500mm |
| Max production speed | 550m/min | 550m/min |
| Flat yarn fibre scope | 60-200tex | 60-200tex |
| Drawing ratio | 4-10 | 4-10 |
| No.of winder | 170Spindles | 210Spindles |
| System installed capacity | 350kw | 460kw |
| System normal operational capacity(about) | 210kw | 276kw |
| Overall dimension(L×W×H) | 34000×3700×3000mm | 35000×3900×2600mm |
| Total weight | 27T | 32T |
