Home > Products > FILAMENT & FLAT YARN > CE STANDARD HIGH PERFORMANCE POLYPROPYLENE BRUSH MONOFILAMENT EXTRUSION LINE
CE STANDARD HIGH PERFORMANCE POLYPROPYLENE BRUSH MONOFILAMENT EXTRUSION LINE
- 10 Set / Sets per Month
- Shanghai
- T/T
Product Details
Place of Origin: | Shanghai, China | Brand Name: | Polypropylene brush monofilament extrusion line | Model Number: | Polypropylene brush monofilament extrusion line |
Machine Type: | Net Machine | Product: | Fishing Net | Material Capabilities: | Yarn |
Condition: | New | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Polypropylene Brush Monofilament Extrusion Line
I. Work Condition of Whole Line
Warehouse/Workshop (Provided by customer) | Construction of foundations, construction works, earthworks, and wall works; Supply of cranes, fork-lifts or other lifting equipment; Mounting materials and tools Dimension (M*M*M): 25(L)×2.3(W)×1.85(H) |
Power supply | Installed power of whole line: 80kw Supply voltage: 3*380V+N+PE; Voltage tolerance: +5%/-5%; Control voltage: 24VDC+220VAC; Frequency: 50HZ+-2% |
Wire/cables/water hose | Wires/cables: From power supply to control cabinet of this production line and all electrical cables from control cabinet to each machine; Water hose: Supply water to machines and pools; |
II. Scope of Supply
No. | Name | Qty. |
1 | SYL-L90×30-580 Extruder | 1set |
2 | Filter, Mould and Melt pump | 1set |
3 | Cooling water tank | 1set |
4 | Seven rollers take-off unit A | 1set |
5 | Hot water tank A | 1set |
6 | Seven rollers take-off unit B | 1set |
7 | Hot water tank B | 1set |
8 | Seven rollers take-off unit C | 1set |
9 | Oil equipment and winder of waster monofilament | 1set |
10 | Winding unit | 1set |
III. Pictures of Machine
1. We design, engineer and manufacture and customized the extrusion line.
2. Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
3. Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our client’s factory
4. Support: We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
CissCo Machinery Co., has been engineering and manufacturing a series of EXTRUSION MACHINERY for more than 20 years and has thus acquired an extensive expertise in the supply of manufacturing machinery; having based ourselves on the features demanded by large companies in more than 30 countries.
Comparing with the low price low quality machine, please note our strong advantages:
1. 20 Years Experiences;
2. European Latest Technology;
3. Easy to Operate, Stable Performance, Good Quality Products, Low Production Cost;
4. Quicker Production Speed, Big Output;
5. Good Material and Well-Known Brand Electrical Parts;
6. Beautiful Appearance;
7. Free Training for Technical Process, Formula and Know-How;
8. Full Time and High Level After-Sale Services.
Contact Us
- Cissco Machinery Co., Ltd.
- Contact nameLouies Liu
- Phone86-21-38726398
- AddressRoom 30B, Yindong Bldg., No. 58, New Jinqiao Road
