POLYESTER ADHESIVE TAPE COATING MACHINE
PET PRECISION ADHESIVE TAPE COATING MACHINE
1. MAIN TECHNICAL PARAMETERS OF POLYESTER ADHESIVE TAPE COATING MACHINE
1.1. Suitable base material: PE film;
1.2. Valid width: 1600mm;
1.3. Coating type: Anilox roller directly coating, anilox roller reverse kiss coating
1.4. Mechanical speed: 60-120m/min
1.5. Heating type: Electrical heating
1.6. Mechanical power: About 65Kw
1.7. Heating power: About 300Kw
1.8. Overall size: 31580mm (L) * 3800mm (W) * 5423mm (H)
1.9. Overall weight: About 40 tons
2. SCOPE OF DELIVERY OF POLYESTER ADHESIVE TAPE COATING MACHINE
NO. |
Name |
Qty. |
1 |
Turret unwinding machine |
1 set |
2 |
Anilox roller coating head |
1 set |
3 |
Drying oven (4m * 6 = 24 m) |
6 sets |
4 |
Cooling roller group |
1 set |
5 |
Four-position winder |
1 set |
6 |
Rectification unit |
3 sets |
7 |
Corona treatment system |
1 set |
8 |
Electrostatic clearing device |
2 sets |
9 |
Electrical control system |
1 set |
10 |
Electrical parts |
1 set |
11 |
Frame |
1 set |
12 |
Pipeline |
1 group |
13 |
Spare parts |
1 group |
3. PICTURES OF POLYESTER ADHESIVE TAPE COATING MACHINE
• We design, engineer and manufacture and customized the extrusion line.
• Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
• Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our client’s factory
• Support: We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
