Special Format 2.1M DX5 High Precision Digital Outdoor Printer

Specification

1.2.1meter printing width solvent printer.
2.outdoor advertisement printer.
3.with1DX5 print head., reach 16 square/hr high speed
4.Adopt USB2.0 output system, printer operate fast and flexible.
5.Double raster controlling system, and auto cleaning ink system,

 automatic take-up system.
6.printer warranty for one year, good after-sale service.

Product Model

UD-211LC

Print head

DX5

Number of Printhead

1Heads

Print head Sequency

1

Maximum Print Width

2100mm

Maximum Media Width

2100mm

printing mode

Print Speed

RD

2 PASS 32 m2/hr

D

3 PASS 21 m2/hr

Standard mode(S)

4 PASS 16 m2/hr

Q

6 PASS 11 m2/hr

High quality mode(HQ)

8 PASS 8 m2/hr

BL

12 PASS 5 m2/hr

Ink Type

Eco Solvent Ink

Ink Color

4Color CMYK

Ink Supply System

Low Ink Detector,Auto or Manual Ink Supply System

Auto Cleaning System

Positive Cleaning Anti-clogged Flash Function

RIP Software

Maintop, PhotoPrint, UltraPrint

Print Interface

USB2.0

Printhead Height

2 to10mm Above Media Adjustable

Media Type

Vinyl,Flex,Polyester,Back-Iit Film,Window Film,etc Roll Media or SheetMedia

Auto Media Feeding System

Equipped(Max.Media Weight 80kg)

Pre-heating & Drying System

Equiped(Drying System Optional)Infra-red Heating System Optional

Clamp

Equipped

Input Power

AC220V 50HZ

Operation Environment

Temperature: 20°C--28°C, Humidity: 40%--60%

Machine Dimension

L3,380 x W990 x H1,260mm / 225KG

Package Dimension

L3,490 x W1,100 x H845mm / 422KG

Shipping info.:

Measurement for 1 set :3.243CBM

How about the warranty of the printer and after-sale service?

(1) One year of warranty.
(2) About the after-sales service,
If the printer has problem, the client can take a picture or video to the technician.
The technician will teach  the client to fix and operate the printer through the internet.
And we will ask the client to send back the board which is wrong to check it.
Believe us. The technician is full of experience, and the sales also keep in touch with the client.
