Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)

Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-1
Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-2
Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-3
Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-4
Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-5
Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370) photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Beijing, China
Brand Name:
PF
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China(mainland)
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Beijing, China
Brand Name PF
Model Number GZP-26 32 40
Type Rotary Tablet Press
Production Capacity 34000~264000pcs/h
Max. Pressure(KN) 100KN
Max. Tablet Thickness(mm) 8 mm
Max. Tablet Diameter(mm) 25mm
Voltage 380V
Power(W) 7.5KW
Weight 1600kg
Dimension(L*W*H) 820*1100*1750mm
Certification GMP
After-sales Service Provided Engineers available to service machinery overseas

Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)



Specifications

Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)

1.Rorary tablet press machine
2. Usage: pahrmaceutical, chemical, food
3. Dia of tablet: 25mm/16mm/13mm
4. Production capacity:39000~198000 pcs/h





Packaging Details:packaging according to export standard
Delivery Detail:30 days

Common Features

 The common Features pof GZP Series and ZTP series:

1 Adopts PLC control with auto protective function

2 Touch screen operation. Operation menu is easy to understand

3 Force-feeding unit with a good applicability to powder

4 Central auto lubrication system

5 Main and pre-pressing, tablets formed twice.

Unique features

 Unique features of GZP series



1  Auto compensation of powder

2  Monitoring pressure of each punches and displays the pressure on the touch screen. There are two chutes for qualified tablets and defective tablets. Defective tablets can be rejected from one chute .

3  Pre-press wheel and main press wheel are sustained by hydraulic system. The hydraulic system will act as a buffer and protector while the pressure is high.

4  Force-feeding system is capable to increase the feeding ability and prevent thick granules separating from fine granules effectively.

5  All the parts are easy to be fixed, disassembled and cleaned.

Technical parameters



        model

data

GZP-26

ZPT-26

GZP-32

ZPT-32

GZP-40

ZPT-40

No. of stations

26

32

40

Tooling type

D

B

BB

Output range (Tablets/h)

34000-171000

42000-211000

52000-264000

Rotation speed range (rpm)

22-110rpm

Main pressure

100KN

Pre-pressure

16KN

Max tablet diameter

Φ25mm

Φ16mm

Φ13mm

Max length of irregular tablet

25mm

19mm

16mm

Diameter of die

Φ38.1mm

Φ30.18mm

Φ24mm

Max. filling depth

20mm

20mm

16mm

Diameter of punch

Φ25.35

Φ19

Length of punch

133.6mm

Pitch circle diameter

370mm

Main motor power

7.5kw

Weight

1450kg

Dimension

820*1100*1750mm







Pitures

 Machine Show

                                                   Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)







Samples



Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)

Hot Selling GZP Series Automatic High-speed Rotary Tablet Press (370)
